Accessories and Dimensions B-13
PowerFlex 40 Adjustable Frequency AC Drive FRN 1.xx - 7.xx User Manual
Publication 22B-UM001I-EN-E
Figure B.8 Dynamic Brake Modules – Dimensions are in millimeters and (inches).
Weights are in kilograms and (pounds).
Figure B.9 Recommended External Brake Resistor Circuitry
Frame Catalog Number Weight
A AK-R2-091P500, AK-R2-047P500, AK-R2-360P500 1.1 (2.5)
B AK-R2-030P1K2, AK-R2-120P1K2 2.7 (6)
335.0
(13.19)
60.0
(2.36)
30.0
(1.18)
17.0
(0.67)
59.0
(2.32)
13.0
(0.51)
405.0
(15.94)
386.0
(15.20)
316.0
(12.44)
61.0
(2.40)
31.0
(1.22)
ROCKWELL
AUTOMATION
CUS
SURFACES MAY BE
ROCKWELL
AUTOMATION
CUS
Frame A Frame B
Power On
R (L1)
S (L2)
T (L3)
Power Source DB Resistor Thermostat
Power Off
M
M
(Input Contactor) M
Three-Phase
AC Input
22B-UM001.book Page 13 Tuesday, May 30, 2017 5:22 PM
