Accessories and Dimensions B-17
PowerFlex 40 Adjustable Frequency AC Drive FRN 1.xx - 7.xx User Manual
Publication 22B-UM001I-EN-E
Figure B.13 Remote (Panel Mount) Small HIM – Dimensions are in millimeters and
(inches) Catalog Number: 22-HIM-C2S
93
(3.66)
25
(0.98)
2m
180
(7.09)
154
(6.06)
77
(3.03)
23.5
(0.93)
67
(2.64)
60
(2.36)
19.1
(0.75)
4.8
(0.19)
22B-UM001.book Page 17 Tuesday, May 30, 2017 5:22 PM
