Rockwell Automation MSR127RTP User Manual

Inputs Safety Outputs Auxiliary Outputs Terminals Reset Type Power Supply Cat. No.
1 N.C., 2 N.C., Light Curtain 3 N.O. 1 N.C. Fixed Auto./Manual 24V AC/DC 440R-N23126
Monitored Manual 440R-N23129
Auto./Manual 115V AC 440R-N23125
Monitored Manual 440R-N23128
Auto./Manual 230V AC 440R-N23124
Monitored Manual 440R-N23127
Removable (Screw) Auto./Manual 24V AC/DC 440R-N23132
Monitored Manual 440R-N23135
Removable (Spring Clamp) Auto./Manual 24V AC/DC 440R-N23132S
Monitored Manual 440R-N23135S
Removable (Screw) Auto./Manual 115V AC 440R-N23131
Monitored Manual 440R-N23134
Auto./Manual 230V AC 440R-N23130
Monitored Manual 440R-N23133
Approximate Dimensions
Dimensions are shown in mm (in.). Dimensions are not intended to be used for installation purposes.
Block Diagram
Typical Wiring Diagrams
Light Curtain, Monitored Manual Reset, Monitored Output Single Channel E-Stop, Automatic Reset, No Output Monitoring
Dual Channel E-Stop, Monitored Manual Reset, Monitored Output Dual Channel Safety Gates, Automatic Reset, Monitored Output

Rockwell Automation MSR127RTP Specifications

General

Brand	Rockwell Automation
Model	MSR127RTP
Category	Relays
Language	English
