Publication 1783-UM002C-EN-P - April 2009 37
Chapter 2
Install the SFP Module (optional)
Grasp the module on the sides, and insert it into the switch slot until you feel
the connector snap into place.
ATTENTION
SFP modules are static sensitive devices. Always use an ESD
wrist strap or similar individual grounding device when
handling SFP modules.
IMPORTANT
Using an SFP module other than those provided by Rockwell
Automation will disable the switch port.
IMPORTANT
Installing and removing an SFP module can shorten its useful
life. Do not remove and insert SFP modules more often than is
absolutely necessary.
ATTENTION
If the SFP module cannot be fully inserted, stop! Do not force the module into
the slot. Rotate the SFP module 180 degrees and try again.
31782-M
