Rockwell Automation STRATIX 8000 1783-MS06T User Manual

46 Publication 1783-UM002C-EN-P - April 2009
Chapter 2
6. Refer to Attach the Power and Relay Connector on page 42 for
instructions on how to connect the power and relay connector to the
front panel.
1 Power source A positive connection 5 Power source B positive connection
2 Power source A return connection 6 Power source B return connection
3 External device 1, relay wire major alarm
connection
7 External device 2, relay wire minor alarm
connection
4 External device 1, relay wire major alarm
connection
8 External device 2, relay wire minor alarm
connection
-
24
!
6
!
24
!
6
!
1
2
3
4
5
6
7
8
