Rockwell Automation STRATIX 8000 1783-MS06T User Manual

Publication 1783-UM002C-EN-P - April 2009 55
Chapter 2
c. Click on the + sign and scroll down until you see the Stratix 8000
switch you want to configure.
d. Click OK.
4. From the Module Properties dialog box, enter this information.
TIP
If you do not see the switch on the list, you may need to obtain
the AOP from the Rockwell Automation support website.
1. Go to http://www.rockwellautomation.com/support/.
2. Click Downloads/RSLogix 5000 I/O Modules Add-on Profiles.
3. Select the 1783-Stratix 8000 Managed Switches Add-on Profile.
On this tab In this field Enter
General Name A name you choose for the switch
Description A description that helps you remember something important about the
switch
IP Address Enter the IP address you added when you performed the Express Setup.
