Points switch with position lights
Package contents
1x Set of 4 points switches with position lights
1x Adhesive xture tape
2x Contact pins
Operating voltage
14 – 16 Volt AC
Application
The switch unit enables 4 points motors to be op-
erated. Four tumbler switches control the points
positions and by means of the switch operated
light diodes, the position of each point is easily
visible, as follows:
Green: Point is set straight
Red: Point is set to turnout
Orange: Faulty operation of one point because
two switches were pressed simultane-
ously.
Manual operation of the point still effects a return
indication of the light signals which is shown cor-
rectly by the corresponding LED.
Attention: The switch unit has a maximum capac-
ity of 0,5 amps.
Installation
The points switch can be xed by means of the
adhesive xture tape or by using screws. In the
latter case, the sides of the switch housing should
be lightly pushed inwards when the base can be
pulled away. At marked points on the base where
plastic is thin one can make holes for the xing
screws.
