Rocstor® Rocsecure® DE51 [10]
CONNECTORS
eSATA Connector
Power Input
ON/OFF Power Switch
Voltage Selector Switch
SYSTEM VIEWS
Front and Rear View
The status indication of each LED
indicator is listed under the LED
INDICATORS section below.
A. Hard drive status indicators
B. Power LED
C. Drive access lock
D. Drive Access doors
F. Secure Key Token Input
Voltage Selector
Power Input
Dip Switch RAID
Configurator
eSATA Interface
C.
Drive Access lock
A.
HDD status indicator LED
B. Power Status LED
