RAID MODE SWITCH SETTING
The RAID Mode switches define what type of RAID will be initialized when the unit is powered
up while the RAID Mode button is held down, as follows:
DIP SWITH POSITION
1 (BZS) *
2 (EZ)
3 (M2)
4 (M1)
5 (M0)
JBOD (FACTORY DEFAULT SETTING)
OFF
OFF **
OFF
OFF
OFF
RAID 0
OFF
ON ***
ON
ON
ON
RAID 1 OR 10
OFF
OFF
ON
ON
OFF
RAID 3
OFF
OFF
ON
OFF
OFF
RAID 5
OFF
OFF
OFF
ON
OFF
CLONE
OFF
OFF
OFF
ON
ON
LARGE
OFF
ON
ON
OFF
ON
NOTE:
* Audible alarm is recommended at all times.
** EZ Mode has no effect when no array is defined.
*** Disabling EZ for RAID 0 and large is strongly recommended.
