1 GENERAL INSTUCTIONS
This appliance is intended for normal household use and not for use in commercial/industrial environment,
in vehicles or on board ships or aircrafts.
The convectors are equipped with a thermostat for setting and automatic maintaining the desired
temperature in the room with system of the room protection from freezing (prevents freezing of the hot-water
heating system with is not in use), with a system of the power step-by-step regulation, with a limiter of the
leaving air (with a self-reset) and Tip-over switch.
Before any operation remove the packaging and check product integrity. In case of defects or damages do
not try to repair it yourself but contact your dealer.
Do not let children play with the packaging and protect the environment by disposing of the packaging in
accordance with the national regulations for waste processing.
Disconnect the power before carrying out any work on the heater.
The convectors are designed for twenty-four-hour operation without constant supervision.
2 TECHNICAL DATA
- Rated supply voltage, V 230±10
- Current frequency, Hz 50±1
- Protected against water projections IP20
- Class of protection from electric current shock II
Other specifications are resulted in table 1
Table 1
3 COMPETNESSY
- Electric convector - 1 pc
- Fixing brackets for wall mounting - 1 set
- Supports - 1 set
- User instruction - 1 copy
- Package - 1 set
4 PREPARATIONS FOR OPERATION
4.1 Unpack the convector. Keep the convector at room temperature not less than one hour after placing the
convector in a warm room from cold in case of the dew fall-out.
4.2 This equipment was designed to be installed in a residence. Please ask your distributor before using it
for any other purpose.
Do not install the convector in a draught that might affect adjustment (for example, under a central
mechanical ventilation unit etc...)
4.3 The convector should be installed according to normal trade practice and in compliance with legislation
in the relevant country (the IEE Wiring Regulations). Check the correspondence of the mains to the data on
the firm label which is on the convector rear wall; check also the mains and the protection devices ability to
with stand the consumption current.
4.4 To stationary installation of convector:
- It is necessary to hold minimum distances from the objects when mounting the convector as shown in
Figure 2, Figure 3 (dimension in cm);
- execute on a wall a marking for fixing (see fig. 1, table 1);
- fix the bracket in any accessible way, having provided reliable fastening of convector in all term of
operation;
- mount the convector on the hook-on brackets.
Table 1
Rated power, kW 0,5 1,0 1,5 2,0 2,5
L, mm 156 288 408 / 276 540 / 396 660
Rated power, kW 0,5 1,0 1,5 2,0 2,5
Rated current, А 2,1 4,3 6,5 8,7 10,8
