Rodgers 795 - MIDI Implementation Chart

49
Rodgers Model: 795 MIDI Implementation Chart Version: 1.0
Function Transmitted Recognized Remarks
Basic Default: 1-3, 12-14 *1 12-14 *1 12=Gt
13=Sw 14=Ped
Channel Changed: 1-16 MIDI GT A only
Default: Mode 3 Mode 3
Mode Messages: X X
Altered: *************** ***************
Note 8-124 36-96
Number True Voice
Velocity Note On: O X
Note Off: O X
After Keys: X X
Touch Channel: X X
Pitch Bender X X
0 O X GS Bank Select
7 O O Div Expression on each
Master Channel
Control (12-14 as listed above)
Change
64 O X MIDI GT A Channel
Program 1-128 (1-12, 20-26) Ch. 12-14 only;
Change True # *************** *************** activates comb. pistons
System Exclusive O *2 O *2
System :Song Pos X X
:Song Sel X X
Common :Tune X X
System :Clock X X
Real Time :Commands X O *3
Aux :Local ON/OFF X X
Mes- :All Notes Off O (123) O (123)
sages :Active Sense O O
:Reset X X
Notes: *1 Able to choose between O and X.
*2 SysEx used for stop changes, combination memory dumps.
*3 Received Start sends current stop and expression status.
Received Stop restores expression to shoe positions.
Received Continue sets expression to values at last Stop.
Mode 1: OMNI ON, POLY Mode 2: OMNI ON, MONO O : Yes
Mode 3: OMNI OFF, POLY Mode 4: OMNI OFF, MONO X : No
