ROE Air Frame - Rigging System

Air Frame Manual No. AF-180709
12
4. Rigging System
Allowable wind [m/s] / height
Height
Max. allowable (3-sec gust) [m/s]
Height
Max. allowable (3-sec gust) [m/s]
10 frames
20.00
6 frames
21.71
8 frames
20.76
5 frames
22.98
Load type
Bracket
Max height
[#frames]
Max height
[m]
Limiting
factor
Only self-weight
Any
25
30
Kingpin
Self-weight + climbing
Any
21
25.2
Kingpin
Self-weight, climbing, falling
Any
21
25.2
Kingpin
Bracing at the bottom
