2.4 Alternative Bracing
A keyhole lock is
provided to connect
with ROE standard
rear bridge stacking
accessory.
Placing clamps on the carbon
parts is not allowed.
To accommodate for this, a ring is
positioned on the bracing’s upright.
This ring can take standard clamps
for 48-51mm tubing.
Baby arm clamps to upright part
