3. Tiles Installation
Connect the tiles and Base Bar by Vertical Connector, and Rear Support Truss by Rear bridge.
4. Stacking Installation
Tile(2×6)Accessories Count:
Base Bar: 2×0.6m, 1×1.2m
Base Truss: 4
Rear Support Truss: 8
Rear Bridge: 8
Connection Plate: 19
Vertical Connector
Rear Bridge
