User Manual P10
Installation:
05
Hanging System
Hanging Bar Diagram:
0.6m Hanging Bar Dimensions:
1.2m Hanging Bar
Optional
Eyebolt
Adjusting Screw
Adjusting Knob
Hanging Clamps
Fixed Seat
Dowel Pin
Magnet Component
589mm
1189mm
188mm
157mm
