ROE MC-7H - Page 11

- 11 -
Stacking System
Stacking Installation
Rear support truss Rear bridge
Base bar Base truss
Before hanging installaon, please make sure the locaon pin is on the top of the bar.
Adjust the level adjusng screw and make the base bar keep horizontal on the ground
Adjust the direcon of the horizontal connectors and make sure one red and one blue
on the top side.
1. Base bars connecon with each other.
0 degree
