9
other nearby devices that transmit infrared.
Acvate the control device to which the photocells are
connected.
With a cylindrical object with a diameter of about 50mm,
interrupt the beam of infrared light several mes right in
the middle of the photocells. Repeat the same operaon
by posioning yourself near the TX photocell, and then
near the RX photocell; perform the operaon in all phases
of operaon of the control device.
If the control device correctly detects each interrupon at
all points, the test is successfully completed.
When installing two or more pairs of photocells, repeat the
same procedure, taking care to check for any interference
between them.
If when interrupng the beam between the photocells the
output contact remains closed(does not switch) but the
LED L3 on the RX switches o too, this signies that there
could be a fault: check that the power supply is sucient
and that the output relays are funconing. If the problem
persists, contact technical support.
7 Maintenance
Perform scheduled maintenance every 6 months and
verifying the cleanliness and operaon of all the photocells.
If there is dirt, moisture, insects or anything else, clean the
photocell and rerun the test procedure.
If presence of oxidaon is detected on the printed circuit,
evaluate its replacement.
8 Disposal
The product must always be uninstalled by qualied
personnel using the appropriate procedures for the proper
removal of the product.
This product is made of various types of materials, some
may be recycled others must be disposed of in compliance
with local recycling and disposal regulaons as they
pertain to this category of product.
The disposal of this product as household waste is
prohibited. Carry out “separate collecon” for disposal in
accordance with the methods established by local
regulaons; or return the product to the retailer when
buying an equivalent new product.
Local regulaons may provide for heavy penales for
illegal disposal of this product.
Warning: some parts of the product may
contain pollutant or hazardous substances,
that if dispersed could cause harmful eects
to the environment and to human health.
9 Declaraon of conformity
The undersigned, represenng the following manufacturer
Roger Technology
Via Bocelli 8
31021 Bonisiolo Mogliano V.to (TV)
DECLARES that the equipment described below:
Descripon: Photocell for automac opening
Model: R90 and G90
Complies with the legal requirements of the following
direcves:
• 2004/108/EEC
• 2006/95/EEC
• 2011/65/EEC
And that all the standards and/or technical specicaons
listed below have been applied:
EN 61000-6-2; EN 61000-6-3
Last two digits of the year in which the labelling was axed
| 14.
Locaon: Mogliano V.to
Date: 26-10-2014 Signature
