10 Remote control function
Once connected to the B74/BCONNECT device and entered the IP address 192.168.10.1
into a web browser, the page that will be displayed will be the ‘remote control’ page.
The remote control function allows you to open and close the automation in both
pedestrian and driveway modes. It also makes it possible to manage and display the
status of the automation for single or double leaf (opening, open, closing, closed) and
to check whether the automation is powered by the primary domestic network or by
the backup battery.
11 Temporary RESET of the B74/BCONNECT device
The temporary RESET procedure allows the B74/BCONNECT device to be momentarily
restarted.
WARNING: the temporary RESET deactivates the Wi-Fi hotspot of the B74/BCONNECT
device, then restarts it automatically.
Communication on the portable device connected to the B74/BCONNECT will be
temporarily lost, but will be restored as soon as the Wi-Fi hotspot is available again.
The latter will be restored as soon as the Wi-Fi hotspot is available again and your
browser page is updated.
Once it has been restored, refresh the web browser page.
If the reconnection is not made or the page refresh fails, follow the instructions in
paragraph 5 again for the P2P connection.
12 Enabling emergency movements
An emergency movement allows the automation to open and close even when there is
an active error on the safety inputs.
Emergency movement enable can be activated from the installer area and enables
residential emergency movement or condominium emergency movement.
When the emergency movement is active, it sets the “man present” function, reduces
the automation speed (both opening and closure), increases the sensibility of detection
of objects along the automation stroke, and modies the ashing mode to indicate the
emergency movement condition. In addition, the emergency movement condition is
shown on the digital controller display.
In case of residential emergency movement, the digital controller will display the
message L-ES. In the case of condominium emergency movement, the digital
controller will display L-EM.
L-ES Residential emergency movement: the movement of the
automation follows a precise cycle (Closed – Opening – Open
– Closing
– Closed). It excludes step, pedestrian and condominium
modes.
L-EM Condominium emergency movement: the movement of the
automation follows a precise cycle (Closed – Opening – Open). It excludes
step, pedestrian and condominium modes, along with the possibility to
close the automation.
13 Managing the digital controller password via the B74/
BCONNECT device
The installer can lock or unlock the digital controller by setting a password. This
password can be set or eliminated via the B74/BCONNECT device in both P2P and
CLOUD mode.
To activate the digital controller password:
1. Go to the installer area
2. Go to the “Control centre” menu
3. Go to “Controller password manager”
4. Enter the desired numeric password in the dedicated elds
5. Press “Save password”
ATTENTION: when the password is active, the installer will be informed of the fact via
the main page of the installer area of the device. Following activation, the installer can
view the parameters but cannot change their values. In order to be able to alter the
values, the installer must unlock the control unit using the password set.
To unlock the digital controller:
1. Go to the installer area
2. Go to the “Control centre” menu
3. Go to “Controller password manager”
4. Enter the password set in the dedicated parameters
5. Press UNLOCK CONTROL UNIT and wait for the button to turn green
14 Updating the rmware of the digital controllers
14.1 Updating via the CLOUD
The digital controller rmware can be updated directly from the B74/BCONNECT
device. To do this:
1. Go to the Roger Technology B2B area (www.rogertechnology.it/it/b2b-2) with a
portable device of your choice
2. Go to the B-CONNECT area
3. Go to the “Control unit update” panel
4. Identify the correct rmware update to be downloaded and check it is compatible
with the controller you want to update
5. Download the rmware update le onto your portable device. ATTENTION: always
make sure the extension of the le you are downloading is “.chx”
6. Select the installation for which you want to update the digital controller
7. Connect your portable device in P2P mode to the B74/BCONNECT
8. Go to the installer area of the B74/BCONNECT device selected
9. Press CONTROL UNIT UPDATE
10. Press the “Choose the le” button and search for the “.chx” update le you wish
to upload. Once selected, press the “Send” button to perform the transfer to the
B74/BCONNECT. ATTENTION: this step will upload the update “.chx” le to the
memory of the B74/BCONNECT device not to the digital controller. In case there
are other “.chx” les in the memory of the B74/BCONNECT make sure that there
is enough memory. Otherwise delete the “.chx” les in the memory and run the
upload procedure again.
11. From the drop-down menu you can select the “.chx” update le you wish to transfer
and install on the digital controller. ATTENTION: before proceeding with the
update, check all data and compatibility of the update le and the digital controller
you wish to update.
12. Once you have selected the correct update le from the drop-down menu, press
“Update control unit”. After starting the digital controller update, the digital
controller will not be available for use.
13. When the update is complete, a message will conrm that the digital controller has
been successfully updated. ATTENTION: the digital controller will restart. During
the restart, the digital controller will not be available for use.
15 Updating the rmware of the B74/BCONNECT device
The rmware version of the B74/BCONNECT device can be updated.
NOTE: the B74/BCONNECT device must be connected to an external internet network
(par. 7) to carry out the rmware update.
1. Access the B74/BCONNECT device in P2P mode
2. Go to the installer area
3. Press “B-CONNECT conguration”
4. NOTE: to check for an update, the B74/BCONNECT device must be connected to an
external network with internet access for at least 60 seconds
5. If an “Update version to” is listed in the “B-Connect Update” section, click on the
“Update” button
6. Wait for the update procedure to complete
7. If the update is successfully completed, the device will restart automatically with
the most recent rmware version installed. Otherwise, a pop-up message informs
the user that the update has failed
ATTENTION: after the update operation is nished the B74/BCONNECT device will
reboot. You may need to refresh your browser page or connect to the B74/BCONNECT
device again.
16 Error alert
• Network password not recognised: you are advised to enter the Wi-Fi network
password (WPA-KEY) again.
• Time-Out page loading: an incomplete page loading may occur if the page is
loaded or updated multiple times within a short period of time. In such cases, clear
the history and cache of the mobile device in use. Once these two operations have
been carried out, log in again to the B74/BCONNECT device.
17 Disposal
This product may only be uninstalled by qualied technical personnel,
following suitable procedures for removing the product correctly and
safely. This product consists of numerous different materials. Some of
these materials may be recycled, while others must be disposed of correctly
at the specic recycling or waste management facilities indicated by local
legislation applicable for this category of product. Do not dispose of this
product as domestic refuse. Observe local legislation for differentiated refuse
collection, or hand the product over to the vendor when purchasing an equivalent new
product.
Local legislation may envisage severe nes for the incorrect disposal of this product.
Warning! Some parts of this product may contain substances that are harmful to the
environment or dangerous and which may cause damage to the environment or health
risks if disposed of incorrectly.
18 Declaration CE of Conformity
The undersigned, representing the following manufacturer:
Roger Technology - Via Botticelli 8, 31021 Mogliano V.to (TV)
DECLARES that the equipment described below:
Description: B74/BCONNECT WI-FI Module
Model: B74/BCONNECT
Is in conformity with the legislative provisions that transpose the following directives:
– 2014/53/UE Directive RED;
– 2011/65/UE Directive RoHS;
– 2015/863/UE Directive RoHS 3
And has been designed and manufactured to meet all the following standards or
technical specications:
EN 300 220-1 V3.1.1;
EN 300 220-2 V3.2.1;
EN 301 489-1 V2.2.3;
EN IEC 62368-1:2020
EN 62368-1:2020
Place: Mogliano V.to Date: 30/09/2020 Signature
