11 Smart Home Monitoring | Yale Door Lock | Manufacturer's Installation Guide

7. Install and secure using (3) M4 x 8mm [8-32 x 5/16"] pan head screws through the latch

part of the lock into the mounting plate.

Important: Before installing the batteries, test the mechanical operation of the lock by

operating the latch. The movement of the bolt should be smooth and unobstructed.

Note: The bolt must be in a retracted (unlocked) position prior to installing the

batteries.

8. Insert four (4) AA alkaline batteries. Install battery cover and tighten Phillips head screw.

Upon powering. The lock will ﬂash and beep several times and respond with the vocal

prompt: "Welcome to Yale Real Living."

Note: Open Door before initial activation of Door Lock.

Activate Door Lock to adjust for proper handling.
