Remote control commands
R&S
®
RTA4000
545User Manual 1335.7898.02 ─ 08
SPECtrum:FREQuency:STARt
Defines the start frequency of the displayed frequency domain at the left display edge:
Center - Span/2
You can set start and stop frequency instead of defining a center frequency and span.
Parameters:
<StartFrequency> Range: Depends on various other settings, mainly on time
base, span/RBW ratio, and center frequency.
SPECtrum:FREQuency:STOP
Defines the stop frequency of the displayed frequency domain at the right display
edge: Center + Span/2
You can set start and stop frequency instead of defining a center frequency and span.
Parameters:
<StopFrequency> Range: Depends on various other settings, mainly on time
base, span/RBW ratio, and center frequency.
SPECtrum:FREQuency:BANDwidth[:RESolution][:VALue] <ResolutionBandwidth>
Defines the resolution bandwidth - the minimum frequency step at which the individual
components of a spectrum can be distinguished.
Parameters:
<ResolutionBandwidth>Range: Depends on various other settings.
SPECtrum:FREQuency:BANDwidth[:RESolution]:RATio <SpanRBWratio>
Defines the ratio of span (Hz) / resolution bandwidth (Hz). The span/RBW ratio is half
the number of points used for FFT which is defined with manual operation in the menu.
Parameters:
<SpanRBWratio> Range: The value is changed in 2^n steps from 2^10 to
2^15 (1024, 2048,4096,8192,16384, 32768).
17.8.3.3 Time settings
SPECtrum:TIME:POSition...............................................................................................545
SPECtrum:TIME:RANGe................................................................................................ 546
SPECtrum:TIME:POSition <TimePosition>
Sets the time position of the analyzed time range.
Parameters:
<TimePosition>
