Español
DFX-15 / DFX-40 / DFX-80 / DFX-150
Batt. Full
Batt. Chg
Model. No
Röhr Logo
Volt. Disp
Processor. Act
Dsgn. JK
INTELLIGENT BATTERY CHARGER
The light will
turn green when
fully charged
The light is yellow whilst charging
MICRO PROCESSOR CONTROLLED
12VDC 1.5A
01. Enchufe
02. Cable de alimentación
03. Abrazadera positiva
04. Abrazadera negativa
05. Luz indicadora de encendido
DFX-15
01
02
03
04
05
