DFX-15 / DFX-40 / DFX-80 / DFX-150
01. Mains plug
02. Power cable
03. Positive clamp
04. Negative clamp
05. LCD display
06. Mode button
07. Battery type button
08. Amperes button
09. Voltage button
10. Battery reconditioning button
DFX-150
Mode
Battery
Type
Amp Volt
11. Battery type display
12. Connection indication
13. Battery / voltage warning
14. High temperature
15. Winter mode
16. Amperes display
17. Amperes / voltage readout
18. Battery reconditioning
19. Charging status
01
03
04
02
05
13
14
11
15
10
17
18
08 09
06 07
16
12
19
