Rohr MIG-135A - Quick Start Guide - Control Panels

MIG-135A / MIG-150R
© Röhr
4
© Röhr
Quick Start Guide - Control Panels
MIG-135A
1. MIG Torch
2. High Temperature Indicator
3. Amp Regulator
4. Amp Regulator
5. Power Switch
6. Wire Feed Speed Regulator
7. Earth Clamp Connection
8. Power Supply
9. Wire Spool
10. Wire Feed Pipe
11. Tension Fastener
12. Wire Guide Dial
1
3 4 52
7 8
6
9
10
11
12
