4. Specifications
Form Factor Micro ATX Industrial Motherboard
CPU
Supports socket mPGA-478 for Intel® Mobile Merom
Processor up to 800MHz FSB
Chipset Intel® GME965 + Intel® ICH8M
System Memory 2 x 240pin DIMM socket up to 4GB DDR2 SDRAM
VGA Controller
Integrated Intel® Graphics Media Accelerator X3100
(Intel® GMA X3100)
24/48 bit LVDS, Dual-channel, CRT, TV-out (support
NTSC/PAL/ SDTV/HDTV), DVI & HDMI (optional)
Ethernet 2 x Intel® 82573V PCIe Gb LAN
I/O Chips Winbond W83627HG
BIOS AMI PnP Flash BIOS
Audio ALC888 HD Codec, 7.1 channel/MIC-in/Line-in/Line-out
Serial ATA
3 x Serial ATA II (SATA) with 300MB/s
2 x External Serial ATA (eSATA)
IDE Interface 1 x Ultra DMA 100/66/33, support 2 IDE devices
Serial Port
6 x COM port (RS-232)
COM2: RS-232/422/485 Selectable
Parallel Port
Floppy
1 x SPP/EPP/ECP mode
1 x Floppy connector
IrDA 1 x IrDA connector
KBMS
1 x Standard PS/2 Keyboard connector
1 x Standard PS/2 Mouse connector
Universal Serial Bus 8 x USB 2.0
DIO 16-bit programmable Digital I/O (8 bit In/ 8 bit Out)
Expansion Interface
1 x PCIe*16 slot
1 x PCIe*1 slot
2 x PCI slot
1 x Mini PCI socket
Hardware Monitor Chip Integrated in W83627HG
Operation Temp. -20ºC ~ +70ºC (-4ºF ~ +158ºF)
Watchdog Timer 255-level Reset
Dimension (L x W) 244 x 244 mm (9.6” x 9.6”)
