5.2. Jumpers & Connectors
5.2.15 IDE1: 40-pin IDE Connector (9)
Pin Description Pin Description
1 IDE RESET 2 GND
3 DATA7 4 DATA8
5 DATA6 6 DATA9
7 DATA5 8 DATA10
9 DATA4 10 DATA11
11 DATA3 12 DATA12
13 DATA2 14 DATA13
15 DATA1 16 DATA14
17 DATA0 18 DATA15
19 GND 20 N/C
21 REQ 22 GND
23 IO WRITE 24 GND
25 IO READ 26 GND
27 IO READY 28 IDESEL
29 DACK 30 GND
31 IRQ14 32 N/C
33 ADDR1 34 ATA66 DETECT
35 ADDR0 36 ADDR2
37 CS#1 38 CS#3
39 IDEACTP 40 GND
Jumpers
5.2.2 JBAT1: CMOS Setup (39)
Pin Mode
1-2 Keep CMOS (Default)
2-3 Clear CMOS
5.2.5 JP8: Compact Flash Select (42)
Pin Mode
Short Master
Open Slave (Default)
5.2.1 JPWR1: AT/ATX Power
Mode (38)
Pin 1-2 Mode
Short AT Mode
Open ATX Mode (Default)
Pin Voltage
1 - 2 +5V
2 - 3 +3.3V (Default)
Pin Description Pin Description
1 GND 2 Drive Density Select 0
3 GND 4 N/C
5 GND 6 N/C
7 GND 8 Index#
9 GND 10 Motor Enabled A
11 GND 12 N/C
13
GND
14 Driver Select A
15 GND 16 N/C
17 GND 18 Direction#
19 GND 20 Step#
21 GND 22 Write Data#
23 GND 24 Write Gate#
25 GND 26 Track 0#
27 GND 28 Write Protect#
29 GND 30 Read Data#
31 GND 32 Head Select#
33 GND 34 Disk Change#
5.2.14 FDD1: 34-pin FDD Connector
(8)
Connectors
5.2.8 ATX1: ATX Power Supply
Connector (2)
Pin Description Pin Description
13 +3.3V 1 +3.3V
14 -12V 2 +3.3V
15 GND 3 GND
16 PS-ON 4 +5V
17 GND 5 GND
18 GND 6 +5V
19 GND 7 GND
20 -5V 8 PW-OK
21 +5V 9 +5VSB
22 +5V 10 +12V
23 +5V 11 +12V
24 GND 12 +3.3V
5.2.7 ATX12V1: ATX +12V Connector
(1)
Pin Description Pin Description
1 GND 3 +12V
2 GND 4 +12V
18
SATA1
19
SATA2
20
SATA3
16
SYSF2
7
CPUF1
1
ATX12V1
DIMM2DIMM1
8
FDD1
9
IDE1
10
LPT1
1
mPGA478
3
KBM1
4
2 x eSATA
2
ATX1
14
LVDS1
22
J2
17
HDMI1
26
CON1
37
COM1
36
COM2
35
COM3
34
COM4
33
COM5
32
COM6
30
SYSF1
25
IR1
31
TPM1
24
USB3
29
USB4
28
DIO1
27
JFRT1
23
CFD1
5
CRT / DVI
15
J1
38
JPWR1
13
LAN2
2 x USB
6
LAN1
2 x USB
21
MINIPCI1
12
INV1
11
TV1
JVLCD1
JBAT1
39
JP8
42
JP7
43
JP6
44
JP5
45
JP4
46
JP2
47
JP1
48
JRS1
41
40
5.2.9 KBM1: PS/2 Keyboard & Mouse
2 x Mini-DIN 6-pin connectors (3)
5.2.11 VGA1: CRT Connector D-SUB
15-pin female + DVI connector female
(5)
5.2.12 LAN1, LAN2 : 10/100/1000 RJ45
+ 2 x USB ports: (6), (13)
5.2.10 ESATA1 : Exteranl Serial ATA
Connector : 2 x eSATA (4)
5.2.16 LPT1: 26-pin Parallel Port
Connector (10)
Pin Description Pin Description
1 STROBE# 2 AFD#
3 PTD0 4 Error#
5 PTD1 6 INIT#
7 PTD2 8 SLIN#
9 PTD3 10 GND
11 PTD4 12 GND
13 PTD5 14 GND
15 PTD6 16 GND
17 PTD7 18 GND
19 ACK# 20 GND
21 Busy 22 GND
23 PE 24 GND
25 Select 26 N/C
5.2.17 TV1:TV-Out Connector (11)
Pin Description
1 TV-CVBS
2 GND
3 TV_Y
4 GND
5 TV_C
6 GND
5.2.6 JP1, JP2, JP4, JP5, JP6, JP7:
COM Port Power Special
Support (43), (44), (45), (46),
(47), (48)
Pin Voltage
1 - 2 Standard signal for Pin-9 (Default)
2 - 3 +12V
5.2.4 JSR1: COM2 RS-232/422/485
Select (41)
Pin Mode
1-2 (Short) RS-232 (Default)
3-4 (Short) RS-422
5-6 (Short) RS-485
It can be congured COM2 to operate in RS-232,
RS-422 or RS-485 mode.
5.2.3 JVLCD1: LCD Panel Voltage
Selector (40)
The voltage of LCD panel could be selected by
JVLCD1 in +5V or +3.3V.
5.2.13 CPUF1/SYSF1/SYSF2: FAN
Connectors (7), (30), (16)
Pin Description
1 GND
2 +12V
3 Fan_Detect
KB
MS
eSATA
eSATA
CRT
DVI
LAN
USB
USB
LAN
USB
USB
HD Audio
