5. Jumpers/ Connectors Quick Reference
Connectors
Label Description
ATX12V1 ATX 12V Connector
ATX1
ATX Power Supply
Connector
KBM1 Keyboard & Mouse
ESATA1
External Serial ATA
Connector
LAN1, LAN2
RJ-45 Connector & stack
USB port
CPUF1
CPU Fan Power
Connector
SYSF1, SYSF2 Fan Power Connector
FDD1 FDD Connector
IDE1 IDE Connector
LPT1 Parallel Port Connector
TV1 TV-Out Connector
SATA1~3 Serial ATA Connectors
J1 HD AUDIO Connector
INV1 LCD inverter Connector
LVDS LVDS Connector
HDMI HDMI Connector
CFD1
CompactFlash Disk
socket
USB3, 4 USB Connector
IR1 Infrared Connector
CON1
RS-422/ 485 Output
Connector
JFRT1 Switches and Indicators
DIO1 Digital I/O Connector
TPM1
Trusted Platform Module
Connector
COM1~6 RS-232 Connectors
VGA1 CRT/ DVI Connector
Jumpers
Label Description
JPWR1
AT/ATX Power Mode
Select
JBAT1 Clear CMOS Setup
JVLCD1
LCD Panel Voltage
Selector
JRS1
COM2 RS-232/422/485
Mode Select
JP8
Compact Flash Mster/
Slave Selec
JP1~2,
JP4~JP7
COM Port Power Special
Support
