Roketa GK-13 - Page 36

REAR WHEEL ASSEMBLY
Item Id Name: QTY (pcs/set)
GK-13-250-04-26 CIRCLIP [INWARD C0NTRACTIVE) Φ86 2
GK-13-250-04-27 ADJUSTER, CHAIN 2
GK-13-250-04-28 CIRCLIP[INWARD CONTRACTIVE] Φ69 2
GK-13-250-04-29 SPLIT PIN Φ3*50 2
GK-13-250-04-30 HEX CONCAVE NUT M18 2
GK-13-250-04-31
BRACKET RR.SPROCKET CENTER HOLE 23.5MM
2
GK-13-250-04-32 HEX NUT M10 8
GK-13-250-04-33
FOUR-SPACED NUT (WITH CLOCKWISE THREAD]
M30
2
GK-13-250-04-34 FLANGE BUSH Φ30*38*10*44.5*3 2
GK-13-250-04-35
L.RR.WHEEL SHAFT Φ29.5*240*35*50
[CLOCKWISE THREAD]
1
GK-13-250-04-36 BRACKET, CHAIN FASTENER 2
GK-13-250-04-37 INNER-HEX BOLT M8*40 4
GK-13-250-04-38 RR.SPROCKET 530/32 2
GK-13-250-04-39 RR.BRAKE DISC 4*220 2
GK-13-250-04-40 LOCKNUT M8 10
GK-13-250-04-41 HEX FLANGE BOLT M8*32 10
GK-13-250-04-42 R.RR.WHEEL SHAFT Φ29.5*24*35*50 1
GK-13-250-04-43 FOUR-SPACED NUT M30 2
GK-13-250-04-44 RR.L.TIRE ASSY 1
GK-13-250-04-44-1 RR.WHEEL 22*10-10 7.1kg 1
GK-13-250-04-44-2 RR.HUB 4.1kg 1
GK-13-250-04-45 RR.R.TIRE ASSY 1
GK-13-250-04-45-1 RR.WHEEL 22*10-10 7.1kg 1
GK-13-250-04-45-2 RR.HUB 4.1kg 1
GK-13-250-04-46 RR.BOLT WHEEL 8
GK-13-250-04-47 R.RR.SWING ARM 1
