5
AD-10Sep. 2017
Location of Controls Parts List
No. Part Code Part Name Description Q’ty
1 5100049857 LED OSRGHC3132A 1
5100024412 LED SPACER LED3X6.5 1
2 05015956 LED BL L-7104SRT (F5229820R0) 3
5100037402 LED SPACER LEDS-7.5S 3
3 05015967 LED L-7104SGT 1
5100037402 LED SPACER LEDS-7.5S 1
4 5100001453 ROTARY POTENTIOMETER RD901F-40-125F-B50K-0CD 6
03344934 R-KNOB (75D522N0R0) 6
******** VR NUT M7 attached to VR 6
5 5100055451 SWITCH EVPAWCD4A 19
5100057242 S-KEYTOP SD 19
6 5100037380 ROTARY POTENTIOMETER RV09BDF-40E1-125F-B50K-00D 6
03344934 R-KNOB (75D522N0R0) 6
******** VR NUT M9 attached to VR 6
7 5100049511 SWITCH PEDAL LED LENS 3
5100050548 THERMAL SHRINKAGE TUBE 15X10.0 3
8 5100049826 SWITCH SKPFACA010 3
5100050211 SWITCH PEDAL RING 3
5100049509 SWITCH PEDAL 3
5100050359 SWITCH PEDAL FOOT 3
5100050360 PEDAL SPRING 3
5100049510 SWITCH PEDAL ESCUTCHEON 3
9 5100047382 ROTARY POTENTIOMETER RV09AF-21-15K-B50K 2
10 5100001342 6.5MM JACK HTJ-064-12IMP (13449155R1) 1
11 5100057969 XLR CONNECTOR CT3-05M-EP 2
12 5100011813 SWITCH (F3159712R0) SV69010F-0202-6V-NP-001 2
13 5100007092 USB CONNECTOR UBR24-4K5J00(F3439908R0) 1
14 04908712 DC JACK KM02020ABM2P (F3439892R0) 1
5100042085 DC JACK HOLDER 1
15 5100031222 SWITCH (F3159716R0) SV71010F-0202-6T-NP 1
16 5100034719 6.5MM JACK HTJ-064-22HSPP 2
5100002917 JACK COVER L 2
17 5100034719 6.5MM JACK HTJ-064-22HSPP 1
18 5100034719 6.5MM JACK HTJ-064-22HSPP 2
To Next Page
