7
AD-10Sep. 2017
Exploded View Parts List
Disassembly Procedure
1. Remove screws (x 6) securing the Bottom Case from underneath. (Plain
View (p. 8), a in View 2)
2. Lift the Bottom Case gently and disconnect the battery wiring from the
circuit board.
3. Detach the Bottom Case.
No. Part Code Part Name Description Q’ty
1 03344934 R-KNOB (75D522N0R0) 12
2 5100050211 SWITCH PEDAL RING 3
3 5100049509 SWITCH PEDAL 3
4 5100050359 SWITCH PEDAL FOOT 3
5 5100050360 PEDAL SPRING 3
6 5100049510 SWITCH PEDAL ESCUTCHEON 3
7 5100049511 SWITCH PEDAL LED LENS 3
8 5100050548 THERMAL SHRINKAGE TUBE 15X10.0 3
9 5100057241 TOP COVER 1
10 5100049507 7-SEG COVER 1
11 5100057242 S-KEYTOP SD 19
5100056291 PANEL SHEET ASSY 1
* This unit includes the following parts.
12 ******** PANEL BOARD 1
13 ******** PEDAL BOARD 1
14 ******** JACK BOARD 1
17 5100058463 RIBBON CABLE 12P L=40X6X6 P=2.0 1
15 5100056290 MAIN BOARD ASSY 1
16 5100050563 FLAT CABLE SML2CD-22X60-BDX6(BL)-P1.0-S4 1
18 5100043624 FLAT CABLE SML2CD-12X52-BDX5(BL)-P1.0-S4 1
19 5100050362 PWB SPACER LCC-25 3
20 5100008058 TWIN BATTERY CASE V6 (G2017620R0) 1
21 5100008059 BATTERY TERMINAL (+) (G2177308R0) 1
22 5100008061 BATTERY TERMINAL (-) 1
23 5100008060 BATTERY TERMINAL (+-) (G2177307R2) 1
24 5100007871 WIRING L=80MM 2P (G3487163R0) 1
25 5100049506 BOTTOM CASE 1
26 5100008057 BATTERY INSULATING SHEET (G2257130R0) 1
27 5100050373 BATTERY LABEL 1
28 5100008056 BATTERY COVER (G2017621R0) 1
29 5100042662 FOOT 4
30 5100005300 FILAMENT TAPE 3M #898 W20MM -
a 5100008243 SCREW 2.6X5 (H5019430R0) BINDING TAPTITE P FEZC 2
b 5100003918 JACK NUT M9X12X2 NI RTC(H5039510R0) 7
c 5100003926 PLAIN WASHER 9X13.5X0.5T NI(H5039158R0) 7
d ******** VR NUT M7 attached to VR 6
e ******** VR NUT M9 attached to VR 6
