Roland CUBE 40XL Service Notes

11
Oct. 2010 CUBE-40XL
fig.wiring-block-40XL.eps@R
ER SUPPLY
POWER SWITCH
TRANSFORMER
2
, +8V, -8V, +3.3V, +1.5V
MUTE CIRCUIT
BTL
IC16
IC17
Power AMP
RECORDING OUT/
PHONES
PS BOARD
SP8
JK403
YKB21-500 6
1
2
3
4
5
7
8
HTJ-035-09ABT
CN12
DELAY/
PLAY/REC/DUB
JK400
YKB21-500 6
1
2
3
4
5
7
8
EFX/REVERB
JK401
YKB21-500 6
1
2
3
4
5
7
8
SELECT/SOLO
JK402
YKB21-500 6
1
2
3
4
5
7
8
AUX
10
11
2
3
1
JACK BOARD
CN400
CN4
CN403
CN5
IC11A
Q6
JK404

Roland CUBE 40XL Specifications

General

Power Output	40W
Speaker	10 inch
Amp Models	8
Effects	Chorus, Flanger, Phaser, Tremolo
Looper	80 seconds
Inputs	Guitar Input, Aux In
Outputs	Recording Out/Phones
Channels	2 (Clean, Lead)
Footswitch	Optional (BOSS FS-5U, FS-6)
COSM Amp Models	Acoustic, JC Clean, Black Panel, Brit Combo, Classic Stack, Metal Stack, Extreme
