Roland DS-90A Service Notes

DS-90/90A Feb. 2000
2
r
t
y
w
b
r
a
u
q
e
q
o
!1
!0
c
i
[PARTS]
No. PART CODE PART NAME Q'ty
q K 17055177 CABINET ASSY (CABIN00016) 1
● 17055155 CABINET ASSY(CABIN00017) 1
w 17055182 BADGE SILVER LOGO "ROLAND" SML (HARDW00028) 1
e 17055183 LED SHEET "DIGITAL IN" LABEL (HARDW00030) 1
r 17055184 1'PORT TUBE (HARDW00032) 2
t 17055185 EDGE GRILL SPKR RING PAINTED PLASTIC (HARDW00034) 1
y 17055191 SPEAKER TWEETER 25 MM/8 OHM S0108C18 (SPEAK00019) 1
u 17055190 SPEAKER WOOFER 160 MM/4 OHM S0604F19 (SPEAK00018) 1
i K G281713500 CHASSIS 1
● G281713501 CHASSIS 1
o G2467412 HEATSINK 1
!0 01905145 SEESAW SWITCH (POWER) SDDJF10100 1
!1 22485109 KNOB 248-109 3
[SCREWS]
No. PART CODE PART NAME Q'ty
a 17055188 WOOD SCREW-BRT 10-20x1' ZINC (SCREW00043) 8
b 17055187 SCREW 6-20x5/8' TORX PAN HEAD TYPE A-B BLK OX (SCREW00042) 4
c 17055186 SCREW #8x3/4' SHT MTL PAN HEAD PHILLIPS BLK OX (SCREW00006) 10
K = DS-90, ● = DS-90A
FRONT VIEW REAR VIEW
LOCATION OF CONTROLS

Roland DS-90A Specifications

General

Brand	Roland
Model	DS-90A
Category	Speakers
Language	English
