DS-90/90A Feb. 2000

INDUCTOR, COIL, FILTER

12449268 BL02RN2-R62T2 FERRITE-BEAD L1 on DA 1

12449426 BLM31B601SPT FERRITE-BEAD L2-L6 on DA (for DS-90A or New DA) 5

12449615 PT-10244-615 PULSE TRANSFORMER FL1 on DA 1

FUSE, FUSE HOLDER

F2559102 5ST 1.25A/250V (230V/240V) FUSE 5x20 F1 on AS 1

# F2559424 5TT 3A/125V (100V/117V) FUSE 5x20 F1 on AS 1

F2029601 FH-1 FUSE COVER F1 on AS 1

12199550RT HTF-015 FUSE HOLDER F1 on AS 2

CONNECTOR

13369913 B4P-VH 4P 7A/250V CONNECTOR CN1 on AS 1

13369664 S4B-PH-K-S(4P) CONNECTOR CN2 on DA. CN2, CN6 on AS 3

13369665 S5B-PH-K-S(5P) CONNECTOR CN5 on AS 1

13369666 S6B PH-K-S(6P) CONNECTOR CN1on DA 1

WIRING, CABLE

# G348920501 490MM WIRING 4P CN2 on AS to CN2 on DA 1

# G3489206 60MM WIRING 4P CN6 on AS to CN3 on DA 1

# G3489207 120MM WIRING 5P CN4 to CN5 on AS 1

# G3489208 150MM WIRING 6P CN3 on AS to CN1 on DA 1

# G348920901 VHR4N L600 + L530 WIRING CN1 on AS to WOOFER & TWEETER. 1

# G3489210 W BLACK 90MM WIRING TER4 on AS to POWER SWITCH 1

# G3489211 W BROWN 90MM WIRING TER7 on AS to POWER SWITCH 1

# H4019130 AWG-18 GND WIRING 70MM WIRING JK1 on AS to CHASSIS 1

# H4039101 AWG-20 UL1430 W ORANGE 180MM WIRING POWER AMP BOARD to POWER TR 1

# H4039102 AWG-20 UL1430 W BROWN 100MM WIRING 3

# H4039103 AWG-20 UL1430 W RED 100MM WIRING 3

# H4039104 AWG-20 UL1430 W ORANGE 100MM WIRING 3

# H4039105 AWG-20 UL1430 W BROWN 140MM WIRING 2

# H4039106 AWG-20 UL1430 W RED 140MM WIRING 2

# H4039107 AWG-20 UL1430 W ORANGE 140MM WIRING 2

# H4039108 AWG-20 UL1430 W BROWN 180MM WIRING 1

# H4039109 AWG-20 UL1430 W RED 180MM WIRING 1

TRANSFORMER

# G2457147 100V/117V TRANSFORMER 1

# G2457148 230V/240V TRANSFORMER 1

AC INLET, OUTLET

00125023 PWI1818INL7 10A/250V AC INLET (3P) JK1 on AS 1

SCREWS

40010245 SCREW 3x6 BINDING BZC for TER1 on DA ( for DS-90 ) 1

40010245 SCREW 3x6 BINDING BZC for TER1 on DA ( for DS-90A ) 2

40013056 SCREW M3x6 PAN MACHINE W/SW+SMALL PW ZCfor POWERAMP BOARD on AS 5

40011312 SCREW 3x8 BINDING TAPTITE P FE BZC for JK2-3 on DA. JK2 on AS 4

40012967 SCREW M3x10

PAN MACHINE SCREW W/SW+PW BZC

for Q1-6. IC5 & HS1 on AS 6

# 40013001 SCREW M4x8 PAN W SEMS BZC for HEATSINK 6

40013012 SCREW M4x10 PAN SEMS FE BZC for TRANSFORMER 4

40012501 SCREW 4x12 BINDING TAPTITE P FE BZC for JK1 on AS 2

40011889 EXTERNAL TOOTH WASHER M4 FECM for CHASSIS GND 1

40011767 FRANGE HEX NUT M4 FECM for TRANSFORMER & CHASSIS GND 5

# 17055186 SCREW #8x3/4' SHT MTL PAN HEAD

PHILLIPS BLK OX (SCREW00006)

for CHASSIS 10

# 17055187 SCREW 6-20x5/8' TORX PAN HEAD

TYPE A-B BLK OX (SCREW00042)

for TWEETER 4

# 17055188 WOOD SCREW-BRT 10-20x1' ZINC (SCREW00043) for WOOFER 8

# 17055189 WOOD SCREW-ZINC #4x3/4'

PAN HEAD PHILLIPS (SCREW00047)

for LED BOARD 2

17048630 VR ACCESSORY NUT M9 3

17048631 VR ACCESSORY WASHER M9 3

PACKING

# 17055178 SHIPPING CARTON (CARTO00065) (for DS-90) 1

# 17055199 SHIPPING CARTON (CARTO00047) (for DS-90A) 1

# 17055179 SHIPPING INSERT TRAY (CARTO00048) for SHIPPING CARTON (for DS-90) 1

# 17055200 SHIPPING INSERT TRAY (CARTO00052) for SHIPPING CARTON (for DS-90A) 1

# 17055180 TUBE INSERT (CARTO00049) for SHIPPING CARTON (for DS-90) 1

# 17055201 TUBE INSERT (CARTO00053) for SHIPPING CARTON (for DS-90A) 1

# 17055181 DIVIDER INSERT (CARTO00050) for SHIPPING CARTON (for DS-90) 1

# 17055202 DIVIDER INSERT (CARTO00051) for SHIPPING CARTON (for DS-90A) 1

# 17055210 OUTER SHIPPING BOX(BRN) (CARTO00051) (for DS-90A) 1

# 17055211 CORNER PAD(GREEN) Z-PARTS for OUTER SHIPPING BOX (for DS-90A) 8

MISCELLANEOUS

G2537710 CAUTION SEAL FUSE CAUTION 117 V 1

G2537608 CAUTION SEAL GND CAUTION 1

# G2247106 CUSHION for SLIDE SWITCH 3

# G2467412 HEATSINK on CHASSIS 1

# G2467111 HEATSINK K217 H=25 on HS1 on AS 1

# F2199507 RS-1 LED BOARD SPACER on LED BOARD on AS 2

# F2199508 RS-57 LED BOARD SPACER on LED BOARD on AS 2

# H2369418 LED-14T LED SPACER on LED1, LED2 on AS 2

H5039705 1741BS-2 187 TERMINAL on TER1-TER8 on AS 8

ACCESSORIES (Standard)

# 17055162 OWNER'S MANUAL JAPANESE (for DS-90)

# 17055212 OWNER'S MANUAL JAPANESE (for DS-90A) 1

# 17055161 OWNER'S MANUAL ENGLISH (for DS-90)

# 17055213 OWNER'S MANUAL ENGLISH (for DS-90A) 1

# G3497133 AC CORD SET 100 V 1

# G3497134 AC CORD SET 117 V 1

# G3497135 AC CORD SET 230 VD 1

# G3497136 AC CORD SET 230 VE 1

# G3497137 AC CORD SET 240 VA 1
