# J5159114 I.C. 74 HC 14 FLAT IC10, IC11, IC12, IC13 on DEB
15169334 I.C. 74 LS 05 N IC1 on MIB
15229718RI I.C. 6N 137 PHOTO-COUPLER IC6 on MIB
15189186 I.C. UPC 4570C OP AMP. IC1, IC2, IC3 on EQB
15189189 I.C. UPC 4570HA VERT. OP.AMP. IC10 on DBB
J5199101 I.C. TDA 7350 POWER AMP IC6, IC7 on PWAB
TRANSISTOR
15119155RI TRANSISTOR BC/560-B Q9 on MIB / Q1 on AB / Q14 on LCB / Q1 on PAB
15119154RI TRANSISTOR BC/549-B Q1, Q3 on MIB / Q12=>Q25 on RCB / Q2 on PAB
15129114 TRANSISTOR 2SC-1815GR Q17 on DBB
15319101 TRANSISTOR 2SC-2412 Q3, Q4, Q5 on AB
15309101 TRANSISTOR 2SA-1037KR CHIP Q7 on CPU
15129427 TRANSISTOR 2SC-2235Y Q16 on DBB
15129164 TRANSISTOR DTC-114ES Q12, Q15 on LCB
15119163 TRANSISTOR RN2227 Q1=>Q11 on LCB
15119430 TRANSISTOR DTA-143 ES Q13 on LCB
# 15329104 TRANSISTOR 2SK-368GR FETCHIP Q8 on CPU
DIODE
15019159RI DIODE 1N-4148 on LCB / RCB / CCB / D2 on PAB /
D1, D2, D3, D4, D7 on MIB
15339105 DIODE DAN-202K D2 on AB / D13, D14 on CPU
# 15339109 DIODE DAP 202K CHIP D12, D15 on CPU
15339108 DIODE DA-204K D1=>D8, D16 on CPU
15039174 DIODE S2S6M D11 on CPU
15029320RI LED DIODE TLHG4401 GREEN on LCB / RCB
15029284RI LED DIODE TLHR4401 RED on LCB / RCB / CCB
J5029110 LED DIODE 3 TLH04400 ORANGE on LCB / RCB
# 01341623 DIODE LED TLN 201 D216 on DBB
# 01342578 PHOTO DIODE TPS 708 D215 on DBB
J5019106 ZENER DIODE BZX79C 5.1V D213, D214 on LCB / D10 on CPU
J5019105 DIODE 1N 4002 D1 on PAB / D1 on AB
RESISTOR
J3919104 RESISTOR ARRAY EXB-A10E-103-J RA1, 2, 6, 7, 8, 9, 10, 15, 16, 27, 28, 29, 30, 31 on CPU
J3919108 RESISTOR ARRAY EXB-V8V-103-JV RA3, 4, 5, 11, 14, 32, 33, 35 on CPU
J3919107 RESISTOR ARRAY EXB-V8V-101-JV RA12, RA13 on CPU
J3919109 RESISTOR ARRAY EXB-V8V-470-JV RA17 => RA26 on CPU
J3919111 RESISTOR ARRAY EXB-V8V-391-JV RA34 on CPU
13819132RI UNINFL.RES. 100 OHM 0.6W 5% R1, 5, 6, 7 on AB / R1=>R8 on LCB
J3809134 UNINFL.RES. 27 OHM 0.6W 5% R23 on LCB
POTENTIOMETER
J3219107 ROT. POTENTIOM. EVUF2AH20B53 VR5 on LCB
00671556 SLIDER POT. NNK-X10-B14 VR4 on LCB
00346178 SLIDER POT. RS30111CA VR3 on LCB
# 13299206 TRIMMER CERMET 20K 5X5 OR VR1 on CPU
13299227RI TRIM.POT. 22KOHM 5X10 H CERMET VR11, VR12 on PAB
CAPACITOR
01015912 POL. COND. 0805 2.2N 5% C93, C95 on AB
15359779 POL.COND. 0805 2.7N 5% C92, C94 on AB
15359776 POL.COND. 0805 390P 5% C63, C64 on AB
J3629144 ELCTRL.COND. 470UF 16V AX C14 on LCB
J3469156 ELECTR. COND. 33U 16V P.5 C1,93,147,148 on CPU / C49,53,54,56,57,58,59,60 on AB
J3629117 ELECTRL.COND. -V 4700UF 25V C3, C47 on PAB
J3629103 ELECTRL.COND. 100U 25V P5 C69,70,71 on CPU / C9,10,13,14,15 on AB / C27 on DEB
C1 on MIB / C1, C2 on PAB
J3629147 ELECTR. COND. 220U 25V P.5 C9, 10, 43, 46 on PAB
J3629133 ELECTROL.COND. 22U 25V P5 C12, C42 on PAB
J3629135 ELECTRL. COND. 470U 35V P5 C2 on IB
J3629104 ELECTRL.COND. 10U 50V P5 C2,15,17,38,74,96, 175, 176 on CPU / C4=>C8,11,12, 96 on AB/
C8 on PAB / C44, 45, 48 on DBB
J3629105 ELECTRL.COND. 47U 50V P5 C118,139,140 on CPU
J3629151 ELECTR. COND. 2.2U 63V P.5 C5, C13 on EQB
J3629107 ELECTRL.COND. 1UF 100V P5 C43 on DBB
J5369103 ELECTR. COND. 100U 16V SMD C40 on XPGS
J5369104 ELECTR. COND. 10U 16V SMD C4, C9, C21, C27 on XPGS
J3629137 ELECTR. COND. 33U 16V H.7 C13, C33, C34, C35, C42 on LCB
J3629149 ELECTR.COND. 100U 16V H.7 C1 on RCB
13649103J0 UNPOL.COND. 10U 16V P5 C1, C2, C97, C101 on AB / C60, C75 on PAB
INDUCTOR, COIL, FILTER
<<EMI>> 22448240 NOISE SUP BL02RN2-R62 L1, L2, L3 on PHB
<<EMI>> 12449370 NOISE SUP. SBT-0160W L5, 7, 9, 10, 11 on MIB / L7, 8, 9, 10 on AB
<<EMI>> 12449326 NOISE SUP. SBT-0460 L6, L12 on MIB / L4 on PHB
<<EMI>> 13529187 NOISE SUP. ELKTR391CA FL1=>FL7 on FC7B
<<EMI>> 12449380 NOISE SUP. EXC-ELDR25V L3, 4, 5, 6 on AB / L1, 2, 3, 4 on LCB
<<EMI>> J2399103 NOISE SUP. ELKS471FA CHIP FL1=>FL6 on CPU
<<EMI>> J2399104 NOISE SUP. EXCCL4532U1 CHIP L2=>L9, L18, 39, 40, 41, 42, 44, 45 on CPU
<<EMI>> 00452034 NOISE SUP. BK2125HM102 CHIP L21=>L38, L43 on CPU
CRYSTAL, RESONATOR
00894023 QUARTZ 20 MHZ MA-406 X1, X3 on CPU / X2 on XPGS
00894034 QUARTZ 16 MHZ MA-406 X2 on CPU
00901912 QUARTZ 24.576 MHZ MA-406 X1 on XPGS
RELAY
12439224RI RELAY DS2YS-12V RL1 on AB / RL1 on PAB
ENCODER
J3119101 ENCODER EVQ-WQK F15-24B ENC1=>ENC5 on CCB / ENC6 on RCB
CONNECTOR
13369898 2P MALE CONN. B2P3-VH CN2 on IB
J3429120 3P MALE CONN. P.2 M CN2 on CPU / CN401 on AFTB
# J3439168 4P MALE CONN. 76384-404 CN402 on AFTB
J3439159 4P MALE CONN. 53254 90° P.2 CN5 on LCBV
13369688RI 4P MALE CONN. P 2.5 M CN1 on IB / CN1, CN3 on PAB
J3439109 5P MALE CONN. P 2.5 M CN7 on AB
J3439125 5P MALE CONN. P.2 M CN4 on RCB / CN13 on DEB
J3439103 6P MALE CONN. P 2.5 M CN2 on AB / CN11 on PHB / CN2 on PAB
J3439121 6P MALE CONN. P.2 M CN7 on LCB / CN6 on AB
13429325 7P FEMALE CONN. P.2.5 JST on EQB
13369592 7P MALE CONN. P.2.5 JST on PAB
J3439113 7P MALE CONN. P 2.5 M CN4 on AB / CN5, CN7 on POWER AMP. B
J3439148 7P MALE CONN. P.2 M CN21 on CPU / CN15 on DBB
13419676RI 8P MALE CONN. P.2.5 CN6, CN11 on CPU / CN2 MIB / CN5 on AB
J3439122 8P MALE CONN. P.2 M CN 10 on CPU / CN3, CN5 on RCB / CN2 on FC7B
J3439106 9P MALE CONN. P 2.5 M CN9, CN10 on CPU / CN3 on AB / CN1 on MIB
J3439151 9P MALE CONN. P.2 M CN11 on LCB / CN6 on RCB
J3439124 10P MALE CONN. P. 2 M 90° CN6 on LCB
J3439141 10P MALE CONN. P.2 M CN8 on LCB / CN14, CN17 on DEB / CN2 on CCB /
CN3 on CPU
J3439146 11P MALE CONN. P.2 M CN4 on CPU / CN1 on LCB / CN3 on CCB / CN18 on DEB
J3439126 12P MALE CONN. P.2 M CN2 on LCB / CN1 on CPU
J3439162 13P MALE CONN. P.2 M CN9 on LCB / CN15, CN16 on DEB / CN1 on CCB
J3439147 14P MALE CONN. P.2 M CN5, 7, 8 on CPU / CN4 on DEB / CN13, 14 on LCB /
CN1 on XPGS, CN1,2 on B.LCD B. / on LCD ASSY
J3439163 15P MALE CONN. P.2 M CN12 on LCB / CN7 on RCB
13419677RI 16P FEM. CONN. AMP 1.27 CN15, CN16 on CPU / CN4 on RB / CN3 on LB
13429314 25P FEM. CONN. D-SUB. DBLC CN19 on CPU
J3439143 34P MALE CONN. P. 1.27 M CN17 on CPU
13369851 50P MALE CONN. P. 1.27 M CN18 on CPU
WIRING, CABLE
00783234 BENDER CABLE (35) (W4PC P.2) (For details refer to WIRING DIAGRAM on page 6)
K3468155 4P CABLE (28) 2N/2V 2C D/R “
K3468156 4P CABLE (90) 2C D/D “
K3468160 4P CABLE ASSY (28/106) (W/4PC) “
# K3468199 7P CABLE (28) 2C D/R “
K3468170 8P CABLE (18) 2C D/R “
K3468186 16P FLAT CABLE (36) 2C “
# K3468198 34P FLAT CABLE (18) 2C “
# K3468197 50P FLAT CABLE (36) 2C “
J3469143 1P CONN. AWG18 (10) YELLOW “
7697239001 7P CABLE ASSY (16) 2C D/R “
7697221001 9P CABLE (32) 2C “
7695008001 16P FLAT CABLE (26) 2C “
# 7700430000 DEBOUNCE WIRING ASSY “
# 7700431000 TOP CBN WIRING ASSY “
# 7700432000 BOTTOM CBN WIRING ASSY “
7698713000 3P CABLE ASSY (78) (W/4PC+4PC) “
7699709000 3P CABLE ASSY (56) (W/4PC+4PC) “
# 7700427000 8P CABLE ASSY (6) 2C P.2 “
7699413000 10P CABLE ASSY (12) 2C P.2 “
# 7700426000 9P CABLE ASSY (6) 2C P.2 “
# 7700424000 11P CABLE ASSY (12) 2C P.2 “
7700123000 14P CABLE ASSY (8) 2C P.2 “
# 7700422000 13P CABLE ASSY (12) 2C P.2 “
# 7700423000 14P CABLE ASSY (20) 2C P.2 “
# 7700425000 15P CABLE ASSY (4) 2C P.2 “
AC INLET
! J3439127 AC INLET 6102-33
SCREW
J2289102 SELF TAP.SCREW 2.9X10 TC TC
J2289126 SELF TAP.SCREW 2.9X 8 TCTCPRBZ
J2289125 SCREW 2.9X10 TC TC PR TROP
J2289130 SCREW 2.9X13 TC TC PR TROP
# J2289220 SCREW 2.9X16 TC TC PR BZ TROP
J2289128 SELF TAP.SCREW 3.5X19 TCTCPRBZ
J2289118 SCREW 2.9X16 TC TC PR BRUN
