15
Fantom-XR
CRYSTAL, RESONATOR
15299170 MC-406 32.768KHZ CRYSTAL X1 on Main board 1
00894034 MA-406 16.000MHZ TE24 CRYSTAL X2 on Main board 1
01340745 MA-406 12MHZ CRYSTAL X4 on Main board 1
02673134 MA-406 16.9344MHZ CRYSTAL X3 on Main board 1
ENCODER
03231912 R-ENCODER EVQB1SZ1720B ROTARY ENCODER W/SW EN1 on Encoder board 1
CONNECTOR
# 02012056 CONNECTOR 28FMN-BTK-A CONNECTOR CN1 on Jack board 1
03014001 B5B-PH-K-S JST(PB FREE) CONNECTOR CN5 on Jack board,CN16 on Main board 2
13369562 B15B-PH-K-S JST CONNECTOR CN2 on Jack board ,CN7 on Phones board 2
03013978 B3B-PH-K-S JST(PB FREE) CONNECTOR CN6 on Phones boar 1
13369665 S5B-PH-K-S(5P) CONNECTOR CN10 on Encoder board 1
02454245 28FMN-SMT-TF CONNECTOR CN23 on Main board,
CN1,CN4 on Sub board
3
# 03125201 CONNECTOR B3B-PH-SM3-TB CONNECTOR CN2 on Sub board 1
02906534 CONNECTOR B5B-PH-SM3-TB CONNECTOR CN3 on Sub board 1
# 03459590 CONNECTOR B2B-PH-SM3-TB CONNECTOR CN11 on Sub board 1
# 03454678 CONNECTOR 24FLT-SM1-TB CONNECTOR CN6 on Sub board 1
# 03125278
CONNECTOR 28FMN-BMTTN-A-TFT
CONNECTOR CN8 on Main board,CN5 on Panel board 1
03230623 54104-5092 CONNECTOR CN18 on Main board 1
03126090 40FMN-SMT-A-TF CONNECTOR CN8 on Exp Base board 1
02010078 TX25-80P-6ST-E1 CONNECTOR CN1,CN4,CN3,CN2,CN6,CN5 on Exp Base
board
6
# 03563401
CONNECTOR 34FMN-SMT-A-TF
CONNECTOR CN7 on Exp Base board 1
03126089 40FMN-BMTTN-A-TFT CONNECTOR CN17 on Main board 1
03345856 34FMN-BMTTN-A-TFT CONNECTOR CN4 on Main board 1
13369592 B7B-XH-A(7P) JST CONNECTOR CN10 on Main board 1
WIRING, CABLE
# 03565889 WIRING W2 1
# 03565890 WIRING W3 1
# 03565901 WIRING W4 1
# 03565912 WIRING 2X80-P2.0-PHR-PHR-F 1
# 03565923 WIRING 5X60-P2.0-PHR-PHR-F 1
# 03565934 BAN CARD BNCD-S-P=0.50-K-50-500 1
# 03565945 BAN CARD BNCD-P=1.00-K-28-120 2
# 03565956 BAN CARD BNCD-P=1.00-K-40-50 1
# 03565967 BAN CARD BNCD-P=1.00-K-34-50 1
# 03566634 WIRING W1 1
02341723 WIRING 3X50-P2.0-PHR-PHR-F 1
03453667 BAN CARD BNCD-P=1.00-K-28-50 1
TRANSFORMER
02019478 (7KQ5) 19832A PULSE TRANS T1 on Jack board 1
SCREW
40561090 SCREW M3X6 HEX SOCKET HEAD SPW NI 4
40454045 SCREW 3X8
FLAT TAPTITEB NI FLANGE SOCKET
4
40011123 SCREW 4X8 BINDING TAPTITE B BZC 8
40011090 SCREW 3X6 BINDING TAPTITE B BZC 10
40011145 SCREW 3X6 FLAT TAPTITE B BZC 6
40011312 SCREW 3X8 BINDING TAPTITE P BZC 3
40011223 SCREW 2.6X6 BINDING TAPTITE P NI 10
40017934 SCREW M3X6
PAN MACHINE W/SW+PW FE ZC
4
40013056 SCREW M3X6
PAN MACHINE W/SW+PW ZC
25
40011490 SCREW M3X6 PAN MACHINE W/SW BZC 3
# 03566623 BOSS NUT M3-L5.5-H8-A5-B4-N3 6
40011745 HEX NUT M4 SPRING NUT FE ZC 2
40010334 SCREW M4X8 BINDING MACHINE FE BZC 1
40011489 SCREW M3X4 PAN MACHINE W/SW BZC 30
PACKING
# 03672601 UPPER PAD 1
# 03672590 SIDE PAD 2
# 03672589 PACKING CASE 1
MISCELLANEOUS
02894367 INSULATING COVER DA-2496 SW-PS 1
12359137 RUBBER FOOT SJ-5012 BLK 4
# 03564567 FRONT PLATE R 1
To Next Page
