MIDI Implementation
16
40 4x 25# 00–7F PART EFX MACRO 00–7F 00 0
40 4x 26# 00–7F PART EFX DEPTH 00–7F 00 0
40 4x 27# 00–7F PART EFX CONTROL1 00–7F 00 0
40 4x 28# 00–7F PART EFX CONTROL2 00–7F 00 0
7Drum Setup Parameters
* m: Map number (0 = MAP1, 1 = MAP2)
* rr: drum part note number (00H–7FH)
Address (H) Size (H) Data (H) Parameter Description
41 m1 rr 00 00 01 00–7F PLAY NOTE NUMBER Pitch coarse
41 m2 rr 00 00 01 00–7F LEVEL TVA level (= NRPN# 26)
41 m3 rr 00 00 01 00–7F ASSIGN GROUP NUMBER Non, 1–127
41 m4 rr 00 00 01 00–7F PANPOT -64 (RANDOM), -63 (LEFT)–+63 (RIGHT)
(= NRPN# 28, except RANDOM)
41 m5 rr 00 00 01 00–7F REVERB SEND LEVEL 0.0–1.0
(= NRPN# 29) Multiplicand of the part reverb depth
41 m6 rr 00 00 01 00–7F CHORUS SEND LEVEL 0.0–1.0
(= NRPN# 30) Multiplicand of the part chorus depth
41 m7 rr 00 00 01 00–01 Rx. NOTE OFF OFF/ON
41 m8 rr 00 00 01 00–01 Rx. NOTE ON OFF/ON
* When the Drum Set is changed, DRUM SETUP PARAMETER values will all be initialized.

Roland fp-30 Specifications

General

Certification	FCC, CE
Sound effects	Ambience, Brilliance
Tones quantity	35
Pedals quantity	1
RMS rated power	24 W
Speaker diameter	120 mm
Number of speakers	2
Metronome tempo range	20 - 250 bpm
Metronome beats per bar	0, 2, 3, 4, 5
Maximum polyphony (notes)	128
Bluetooth version	4.0
USB connector type	USB Type-A, USB Type-B
Headphone connectivity	3.5 mm
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (max)	22 W
Power consumption (min)	3 W
Built-in display	No
Country of origin	Malaysia
Tuning frequency	415.3 - 466.2 Hz
Demo songs quantity	30
Transposition range	-6 - 5 octave(s)
Sound pressure level	120 dB
Product color	White
Keys quantity	88 keys
Number of keyboard sensitivity levels	5

Weight and Dimensions

Depth	284 mm
Width	1300 mm
Height	150 mm
Weight	14100 g
