MIDI Implementation
5
9 Channel Mode Messages
7All Sounds O (Controller Number 120)
Status 2nd byte 3rd byte
BnH 78H 00H
n = MIDI channel number: 0H–FH (ch.1–ch.16)
* When this message is received, all currently-sounding notes on the
corresponding channel will be turned o immediately.
7Reset All Controllers (Controller Number 121)
Status 2nd byte 3rd byte
BnH 79H 00H
n = MIDI channel number: 0H–FH (ch.1–ch.16)
* When this message is received, the following controllers will be set to their reset
values.
Controller Reset value
Pitch Bend Change ±0 (Center)
Polyphonic Key Pressure 0 (o)
Channel Pressure 0 (o)
Modulation 0 (o)
Expression 127 (max)
Hold 1 0 (o)
Portamento 0 (o)
Sostenuto 0 (o)
Soft 0 (o)
RPN unset; previously set data will not change
NRPN unset; previously set data will not change
7Local Control (Controller Number 122)
Status 2nd byte 3rd byte
BnH 7AH vvH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
vv = Control value: 00H, 7FH (0,127)
00H: Local O
7FH: Local On
7All Notes O (Controller Number 123)
Status 2nd byte 3rd byte
BnH 7BH 00H
n = MIDI channel number: 0H–FH (ch.1–ch.16)
* When All Notes O is received, all notes on the corresponding channel will be
turned o.
However if Hold 1 or Sostenuto is ON, the sound will be continued until these are
turned o.
7OMNI OFF (Controller Number 124)
Status 2nd byte 3rd byte
BnH 7CH 00H
n = MIDI channel number: 0H–FH (ch.1–ch.16)
* The same processing will be carried out as when All Notes O is received.
7OMNI ON (Controller Number 125)
Status 2nd byte 3rd byte
BnH 7DH 00H
n = MIDI channel number: 0H–FH (ch.1–ch.16)
* OMNI ON is only recognized as “All notes o”; the Mode doesn’t change (OMNI
OFF remains).
7MONO (Controller Number 126)
Status 2nd byte 3rd byte
BnH 7EH mmH
n = MIDI channel number: 0H–FH (ch.1–ch.16)
mm = mono number : 00H–10H (0–16)
* The same processing will be carried out as when All Sounds O and All Notes O
is received, and the corresponding channel will be set to Mode 4 (M = 1)
regardless of the value of “mono number.”
7POLY (Controller Number 127)
Status 2nd byte 3rd byte
BnH 7FH 00H
n = MIDI channel number: 0H–FH (ch.1–ch.16)
* The same processing will be carried out as when All Sounds O and All Notes O
is received, and the corresponding channel will be set to Mode 3.

Roland fp-30 Specifications

General

Certification	FCC, CE
Sound effects	Ambience, Brilliance
Tones quantity	35
Pedals quantity	1
RMS rated power	24 W
Speaker diameter	120 mm
Number of speakers	2
Metronome tempo range	20 - 250 bpm
Metronome beats per bar	0, 2, 3, 4, 5
Maximum polyphony (notes)	128
Bluetooth version	4.0
USB connector type	USB Type-A, USB Type-B
Headphone connectivity	3.5 mm
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (max)	22 W
Power consumption (min)	3 W
Built-in display	No
Country of origin	Malaysia
Tuning frequency	415.3 - 466.2 Hz
Demo songs quantity	30
Transposition range	-6 - 5 octave(s)
Sound pressure level	120 dB
Product color	White
Keys quantity	88 keys
Number of keyboard sensitivity levels	5

Weight and Dimensions

Depth	284 mm
Width	1300 mm
Height	150 mm
Weight	14100 g
