4
❍Cutoff (Controller number 74)
Status 2nd byte 3rd byte
BnH 4AH vvH
n = MIDI channel number : 0H - FH (ch.1 - 16)
vv = Cutoff value (relative change) : 00H - 7FH (-64 - 0 - +63)
* Not received on Tone Wheel Organ.
*With certain tones, the function may not work.
❍Decay Time (Controller number 75)
Status 2nd byte 3rd byte
BnH 4BH vvH
n = MIDI channel number : 0H - FH (ch.1 - 16)
vv = Decay Time value (relative change) : 00H - 7FH (-64 - 0 - +63)
* This MIDI message will change on GM2 Tones only.
*With certain tones, the function may not work.
❍Vibrato Rate (Controller number 76)
Status 2nd byte 3rd byte
BnH 4CH vvH
n = MIDI channel number : 0H - FH (ch.1 - 16)
vv = Vibrato Rate value (relative change) : 00H - 7FH (-64 - 0 - +63)
* This MIDI message will change on GM2 Tones only.
*With certain tones, the function may not work.
❍Vibrato Depth (Controller number 77)
Status 2nd byte 3rd byte
BnH 4DH vvH
n = MIDI channel number : 0H - FH (ch.1 - 16)
vv = Vibrato Depth Value (relative change) : 00H - 7FH (-64 - 0 - +63)
* This MIDI message will change on GM2 Tones only.
❍Vibrato Delay (Controller number 78)
Status 2nd byte 3rd byte
BnH 4EH vvH
n = MIDI channel number : 0H - FH (ch.1 - 16)
vv = Vibrato Delay value (relative change) : 00H - 7FH (-64 - 0 - +63)
* This MIDI message will change on GM2 Tones only.
*With certain tones, the function may not work.
❍Portamento Control (Controller number 84)
Status 2nd byte 3rd byte
BnH 54H kkH
n = MIDI channel number : 0H - FH (ch.1 - 16)
kk = source note number : 00H - 7FH (0 - 127)
*A Note-on received immediately after a Portamento Control message will change
continuously in pitch, starting from the pitch of the Source Note Number.
* If a voice is already sounding for a note number identical to the Source Note Number,
this voice will continue sounding (i.e., legato) and will, when the next Note-on is
received, smoothly change to the pitch of that Note-on.
* The rate of the pitch change caused by Portamento Control is determined by the
Portamento Time value.
❍Effect 1 (Reverb Send Level) (Controller number 91)
Status 2nd byte 3rd byte
BnH 5BH vvH
n = MIDI channel number : 0H - FH (ch.1 - 16)
vv = Reverb Send Level : 00H - 7FH (0 - 127)
❍Effect 3 (Chorus Send Level) (Controller number 93)
Status 2nd byte 3rd byte
BnH 5DH vvH
n = MIDI channel number : 0H - FH (ch.1 - 16)
vv = Chorus Send Level : 00H - 7FH (0 - 127)
❍RPN MSB/LSB (Controller number 100, 101)
Status 2nd byte 3rd byte
BnH 65H mmH
BnH 64H llH
n = MIDI channel number : 0H - FH (ch.1 - 16)
mm = upper byte (MSB) of parameter number specified by RPN
ll = lower byte (LSB) of parameter number specified by RPN
<<< RPN >>>
Control Changes include RPN (Registered Parameter Numbers), which are extended.
When using RPNs, first RPN (Controller numbers 100 and 101; they can be sent in any
order) should be sent in order to select the parameter, then
Data Entry (Controller numbers 6 and 38) should be sent to set the value. Once RPN
messages are received, Data Entry messages that is received at the same MIDI channel after
that are recognized as changing toward the value of the RPN messages. In order not to
make any mistakes, transmitting RPN Null is recommended after setting parameters you
need.
* Not received on Tone Wheel Organ.
This device receives the following RPNs.
RPN Data entry
MSB, LSB MSB, LSB Notes
00H, 00H mmH, llH Pitch Bend Sensitivity
mm: 00H - 18H (0 - 24 semitones)
ll: ignored (processed as 00H)
Up to 2 octave can be specified in semitone steps.
00H, 01H mmH, llH Channel Fine Tuning
mm, ll: 20 00H - 40 00H - 60 00H
(-4096 x 100 / 8192 - 0 - +4096 x 100 / 8192 cent)
00H, 02H mmH, llH Channel Coarse Tuning
mm: 10H - 40H - 70H (-48 - 0 - +48 semitones)
ll: ignored (processed as 00H)
7FH, 7FH ---, --- RPN null
RPN and NRPN will be set as “unspecified.” Once this setting has been made, subsequent
Parameter values that were previously set will not change.
mm, ll: ignored
●Program Change
Status 2nd byte
CnH ppH
n = MIDI channel number : 0H - FH (ch.1 - 16)
pp = Program number : 00H - 7FH (prog.1 - prog.128)
●Channel Pressure
Status 2nd byte
DnH vvH
n = MIDI channel number : 0H - FH (ch.1 - 16)
vv = Channel Pressure : 00H - 7FH (0 - 127)
* The resulting effect is determined by System Exclusive messages. With the initial
settings there will be no effect.
●Pitch Bend Change
Status 2nd byte 3rd byte
EnH llH mmH
n = MIDI channel number : 0H - FH (ch.1 - 16)
mm, ll = Pitch Bend value : 00 00H - 40 00H - 7F 7FH (-8192 - 0 - +8191)
■Channel Mode Messages
●All Sounds Off (Controller number 120)
Status 2nd byte 3rd byte
BnH 78H 00H
n = MIDI channel number : 0H - FH (ch.1 - 16)
* This MIDI message will change on GM2 Tones only.
*When this message is received, all notes currently sounding on the corresponding
channel will be turned off.
