Roland FR-4X User Manual

2
Introduction
Attaching the Straps
1. Remove the strap.
The FR-4x comes with two shoulder straps that have Velcro
fasteners on each end.
2. Place the FR-4x in a stable location.
3. Pass one strap through the holder ring on the
display side.
MEMO
The two straps are of dierent lengths. Attach the shorter strap
to the left shoulder side.
4. Place the Velcro fasteners together to secure the
strap.
5. Firmly press together the entire surface of the Velcro
fastener so that the strap does not come loose.
6. In the same way, attach the other strap by repeating
steps 3–5.
The ends of the straps will be as shown in the illustration.
7. Pass the opposite end of the strap through the
holder ring on the side of the jacks.
8. Place the Velcro fastener together to secure the
strap.
9. Firmly press together the entire surface of the Velcro
fastener so that the strap does not come loose.
10. Use the buckle to adjust the length of the shoulder
strap.
11. In the same way, attach the other strap by repeating
steps 7–10.
Adjusting the Bass Strap
On the left-hand button keyboard
side, there is a belt through which
you can pass your left hand to open
and close the bellows.
Use the Velcro fastener to adjust
the length of the bass strap as
appropriate for the size of your
hand.

Roland FR-4X Specifications

General

Type	Piano accordion
Keys quantity	37 keys
Tones quantity	16
RMS rated power	22 W
Speaker diameter	100 mm
Bass reed quantity	5
Cassotto simulation	Yes
Chord reed quantity	3
Treble reed quantity	7
Organ sounds quantity	32
Number of bass buttons	120 buttons
User programs quantity	98
Chorus effects quantity	8
Maximum polyphony (notes)	128
Number of tweeter drivers	1
Orchestral sounds quantity	162
Number of built-in speakers	2
Display type	LCD
Display number of lines	4 lines
Housing color	Black
Battery type	AA
Operating time	5 h
Battery capacity	2000 mAh
Power source type	Battery

Weight and Dimensions

Depth	270 mm
Width	481 mm
Height	430 mm
Weight	8900 g
