Installing a Memory Card
You don’t have to turn the JUNO-Gi off to change memory cards.
Here’s how to format a card for use in the JUNO-Gi:
1 Insert the new card in the JUNO-Gi’s rear-panel SD RECORDER/
BACKUP card slot until its spring-catch clicks.
SDHC Memory Card
2 If it’s not already powered-up, turn on the JUNO-Gi.
3 Press the MENU button to display the Top Menu
window.
4 Select Utility, as shown below, and then press the
ENTER button.
5 Press 4 once, and then 6 once to highlight SD Card Format as
shown here:
The JUNO-Gi asks you if you’re sure you want to proceed.
Formatting an SD/SDHC Card
Removing the Factory-Installed SD Card
The JUNO-Gi ships with a memory card pre-installed. Before installing a new
card, you’ll need to remove it. Here’s how:
1 Start by using a small Phillips-head screwdriver to remove the two
screws holding in the SD card protector that covers the SD card slot.
Remove the two screws.
This protector keeps the card in place during shipping—you may want
to use the protector to keep a card safely installed onstage and/or
when you move your JUNO-Gi.
2 Press the edge of the installed card all the way into its slot until you
hear its spring-catch release, and then remove the card.
Unlocking a Card for Use
Each memory card has a LOCK slider. When this slider’s
engaged, no data can be written to the card, which
means nothing on the card can be inadvertently
erased.
Before installing a card onto which you’ll be recording,
be sure that the LOCK switch is in its Off position so
you can record onto the card after installation.
When you’ve finished recording on a card, you can slide the LOCK
switch down to safeguard its contents.
Slide the switch up to
record on the card
