JUPITER-Xm Version 1.10 Supplementary Manual
AIRA LINK is Supported
You can use AIRA LINK to connect the AIRA MIXER MX-1 with
the JUPITER-Xm via a single USB cable. This lets you easily enjoy
synchronized performance using I-ARPEGGIO.
You can also operate multiple JUPITER-X/Xm units together.
NOTE
In order to use this function, the SYSTEM parameter USB Driver
must be set to “VENDOR.” For details, refer to “Owner’s Manual.”
Settings on the JUPITER-Xm
1. Press the [MENU] button.
2. Use the [1] knob to select “SYSTEM,” and then press the
[ENTER] button.
You can also make this selection by using the PAGE [ ] [ ]
buttons instead of the [1] knob.
3. Use the [1] knob to select “Sync Mode,” and use the [2]
knob to specify “AUTO” or “USB.”
4. Press the [MENU] button when you’re finished making
settings.
Parameters Added
SYSTEM Parameter
Parameter Value Explanation
AGING
Warm-Up
OFF, ON, FAST,
FIXED
Specifies whether the character of the sound
(pitch variance) changes according to the
varying internal temperature of this unit.
This has an effect only on analog synthesizer
models.
The internal temperature value is shown
in the upper right of the top screen of the
scene.
OFF: The character of the sound is not
affected by the temperature. Nor is there a
temperature indication in the SCENE screen.
ON: The internal temperature starts at the
value specified by Aging Init Temp, and
changes to the actual temperature (REAL).
Although it depends on the temperature
difference, the REAL temperature is reached
in approximately ten minutes. After reaching
the REAL temperature, the setting follows
the actual temperature change.
FAST: The internal temperature starts at
the value specified by Aging Init Temp, and
then quickly (in approximately ten seconds)
changes to the actual temperature (REAL)
when you play the keyboard. After reaching
the REAL temperature, the setting follows
the actual temperature change.
FIXED: The internal temperature is fixed at
the value specified by Aging Init Temp, and
the character of the sound is maintained at
that point.
Init Temp
REAL,
0–60°C/
32–140°F
Specifies the initial internal temperature for
Aging.
REAL: The internal temperature that
is actually measured will be the initial
temperature.
0–60°C/ 32–140°F: Virtually specifies the
initial internal temperature (Centigrade/
Fahrenheit).
Age
OFF,
1–100 years
Simulates the aging of an analog
synthesizer’s internal components.
Increasing this value changes the sound as
it would be on a unit that is a corresponding
number of years old. This is valid only for
sounds of an analog synthesizer model.
ARPEGGIO
Arp Sync (*1)
OFF, BEAT,
MEASURE
Specifies the synchronization setting for
arpeggio performance when connected
to an external device and playing in
synchronization.
OFF: Does not synchronize to measures or
beats. Arpeggio performance starts at the
moment that MIDI messages are received.
BEAT: Synchronizes to beats. Arpeggio
performance starts at the next beat after
MIDI messages are received.
MEASURE: Synchronizes to measures.
Arpeggio performance starts at the first beat
of the next measure after MIDI messages are
received.
(*1) This is valid only if Sync Mode is “MIDI” or “USB.”

Roland Jupiter-Xm Specifications

Power

dc voltage	12 V
current draw	1, 500 mA
battery type	Ni-MH battery (AA, HR6) x 8
battery life	approximately 3.5 hours

Display

display type	Graphic LCD
display resolution	128 x 64 dots

Audio

speaker amplifier power	4 W x 2
full range speaker size	3.5 x 8 cm x 2
tweeter size	2 cm x 2

Weight and Dimensions

weight	4.4 kg, 9 lbs 12 oz
width	576 mm, 22-11/16 inches
depth	308 mm, 12-1/8 inches
height	93 mm, 3-11/16 inches
