2
LOCATION OF CONTROLS
Dec, 1997
KC-100
All knobs are
KNOB (7098605000)
POTENTIOMETER
RK11K112 100KB
(01120112)
POTENTIOMETER
RK11K112 20KB CC
(01120134)
POTENTIOMETER
RK11K112 10KB
(01120145)
LED L-53HD (15029139)
BUTTON (22497565)
SWITCH
SDDLB1-B-D-2 TV-5
(13129160)
JACK
YKB21-5006
(13449252)
CONTROL PANEL
JACK
YKB21-5012
(13449146)
JACK
YKB21-5074
(13449275)
CANNON JACK
NC3FAH-1 (00679778)
JACK
