12
Jan. 2014 ME-80
Parts List
fig.-part1-e.eps
Safety Precautions:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
Note: The parts marked # are new. (initial parts) The description “Q’ty” means a necessary number of the parts per one product.
Due to one or more of the following reasons,
parts with parts code ******** cannot be supplied as service parts.
• Part supplied only as a component in a complete assembly
• Copyright does not permit the part to be supplied
• Part is sold commercially
CASING
#
5100037540 TOP COVER 1
5100002398 7 SEG COVER (G2567172R0) 1
5100011392 VR PEDAL 1
5100011395 PEDAL PLATE 1
# 5100037544 SW PEDAL ESCUTCHEON 4
# 5100037545 SW PEDAL FRONT 4
# 5100037546 SW PEDAL REAR 4
# 5100037541 BOTTOM COVER 1
04560878 BATTERY COVER RTC #G2027602R0 1
CHASSIS
#
5100038986 BATTERY CASE SET 1
5100011394 PEDAL HOLDER 1
KNOB, BUTTON
03344934
R-KNOB (75D522N0R0) 30
12499175 BUTTON JSPUE0011A 1
# 5100037543 KEYTOP UNIT 1
SWITCH
01780101 TACT SWITCH SKQKABD010 4
03344723 TACT SWITCH SKQKAKD010 8
01899989 PUSH SWITCH SPUP19-2N-LB2 1
JACK, EXT TERMINAL
5100006474
3.5MM JACK HTJ-035-10ABZ(F3439911R0) 2
5100001342 6.5MM JACK HTJ-064-12IMP (13449155R1) 3
04908701 ADAPTOR JACK KM02018ABM1P(F3439875R0) 1
5100017587 USB CONNECTOR UBR23-4K5100(F3439933R0) 1
PWB ASSY
# 5100037421 MAIN BOARD ASSY 1
# 5100037426 PANEL SHEET ASSY 1
* This unit includes the following parts.
#
******** PANEL BOARD 1
# ******** JACK BOARD 1
# ******** EXP BOARD 1
DIODE
5100001581
LED BL A-552SR-A B/W (F5029412R0) 1
5100001582 LED BL L-323SRDT (F5229810R0) 2
05015956 LED BL L-7104SRT (F5229820R0) 16
# 05015967 LED L-7104SGT 1
POTENTIOMETER
5100001449 POTENTIOMETER (F3279804R0) RD901F-40-125F-B50K-06D 1
# 5100037572 ROTARY POTENTIOMETER RD901F-40-125F-B50K-09D 1
5100001452 POTENTIOMETER (F3229205R0) RD901F-40-125F-B50K-0BD 1
# 5100001455 ROTARY POTENTIOMETER RD901F-40-125F-B50K-0DD 4
01016167 11M/M ROTARY POTENTIOMETER RK11K1140AFG 10KX1 1
# 5100037380 ROTARY POTENTIOMETER RV09BDF-40E1-125F-B50K-00D 23
WIRING, CABLE
#
5100037403 FLAT CABLE SML2CD-28X80-BDX6(BL)-P1.0-S4 1
# 5100037404 WIRING W1 (EXP) 1
# 5100037405 WIRING W2 (INPUT) 1
To Next Page
