Roland TD-7 Service Notes

Nov.
1992
ierial
number
applied
SNO.ZE43750-ZE
*****
SNO.ZE43750-ZE
*****
Contents of
change
A
part was added.
R111
4.7KQ
iervice
response
These
changes have
been made
for all products.
There is no
need
for
additional service
response.
MAIN
BOARD(pcb No.22935352_01)
R111
added{iiijp)
View from
components side.
Fig.3.(El3)
TD-7
17
