Roland TR-727 - External Connections and Synchronization

9
MEMORY
CARTRIDGE
The
Memory
Cartridge
M-64
is an
optional
extra
whicli
will save
and
load
data
instantly
instead
of
using
a
tape
recorder.
It
acts
as
additional
mennory
to
enable
three
times
more
capacity
of
Tracks
to
be
held by
the
Composer
at
any
one
time.
When
many
tracks
are
needed
during a
live
performance,
new
tracks
can
be
loaded
into
the
Composer
during
a
break
or
intermission,
after
the old
ones
have
been
performed.
Memory
Cartridge
also
permits
the
safe
storage
of data
which
might
otherwise
be
lost
through
being
accidentally
written
over.
You
may
consider
the
internal
memory
of
the
com-
poser
as
Bank
1
,
the
Memory
Cartridge as
Bank 2
and
3.
The
data
in
the
Cartridge
can
be
used
in
exactly
the
same
way as
using
the
data
in
the
Composer's
internal
memory.
Just
note
that
to
save
the
data
in
the
cartridge
onto a
tape,
it
should
be
loaded
from
the
cartridge
into
the
composer
then
saved
onto a
tape,
and
vice-versa.
To
operate
the
Memory
Cartridge:
Load
the
cartridge by
inserting it
into its
slot
located
at
the
upper left of the
composer's
front
panel.
Before
connecting
the
Memory
Cartridge to
the
Composer,
be sure that it is
entered
to
the Track
Playing
mode,
the
rhythm is
not
running
and the
Protect
Switch on
the
Cartridge is
set to
the
ON
position.
The
ON/OFF
operation
of the
Protect
Switch
should
always
be
done
while in
the
Track
Play
mode.
a.
Selecting
a
Bank
Enter the
Track
Playing
mode
with
the
rhythm
not
running.
Then, press
the
Cartridge
Key
(Enter
Key)
while
holding
the
Shift Key
down, and
the
bank
moves as
shown
below.
CD
ENTER
XmRTRIDGe
Indicator
ACCENT
Bank
Number Indicator
dark
red
green
Bank
Composer's
memory
(Bank 1)
Memory
Cartridge
(Bank
2)
Memory
Cartridge
(Banks)
MEMORY
PROTECT
SWITCH
