MST FX1 INS Sw (Master Effect 1 Insert Switch)
This sets how the effects are connected.
Off: There is no Insert.
On: Inserts in both channels of the stereo effect.
4. Press PARAMETER [ ].
“MST FX1 Ins Send=” appears in the display.
5. Rotate the TIME/VALUE dial.
MST FX1 Ins Send (Master Effect 1 Insert Send Level)
This adjusts the level of the signal (0–127) sent to the Insert effect. Set the initial
value to “100.”
6. Press PARAMETER [ ].
“MST FX1 Ins Rtn=” appears in the display.
7. Rotate the TIME/VALUE dial.
MST FX1 Ins Rtn (Master Effect 1 Insert Return Level)
This adjusts the level of the signal (0–127) returned from the Insert effect. Set the
initial value to “100.”
8. Press [PLAY (DISPLAY)].
Return to Play condition.
9. You can insert FX2 in the same way. In this case, perform step 1 so that
“MST FX2 INS Sw=” is displayed.
Adding the Sound with the Effect Applied to the Direct Sound (Send/Return)
When adding the sound with effect to the direct sound, such as is done with
reverb or delay, use the EFFECT bus.
With some effects, while you can have output of both the direct sound and effect
sound, it’s usually better to have the effect sound output separately. The direct
sound and effect sound are adjusted with each channel fader. The present signal
flow is shown below.
