MIDI Implementation
❍Balance (Controller number 8)
Status 2nd byte 3rd byte
BnH 08H vvH
n = MIDI channel number: 0H - FH (Ch.1 - 16)
vv = Balance: 00H - 7FH (0 - 127)
❍Panpot (Controller number 10)
Status 2nd byte 3rd byte
BnH 0AH vvH
n = MIDI channel number: 0H - FH (Ch.1 - 16)
vv = Panpot: 00H - 40H - 7FH (Left - Center - Right),
* Not received in Performance mode when the Receive Pan parameter (PERFORM/MIDI)
is OFF.
* In Performance mode the Part pan parameter (PERFORM/PART) will change.
❍Expression (Controller number 11)
Status 2nd byte 3rd byte
BnH 0BH vvH
n = MIDI channel number: 0H - FH (Ch.1 - 16)
vv = Expression: 00H - 7FH (0 - 127)
* Not received when Tone Receive Expression parameter (PATCH/TONE or RHYTHM/
TONE) is OFF.
* Not received in Performance mode when Receive Expression parameter (PERFORM/
MIDI) is OFF.
❍Hold 1 (Controller number 64)
Status 2nd byte 3rd byte
BnH 40H vvH
n = MIDI channel number: 0H - FH (Ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0-63=OFF, 64-127=ON
* Not received when Tone Receive Hold-1 parameter (PATCH/TONE or RHYTHM/
TONE) is OFF.
* Not received in Performance mode when Receive Hold-1 parameter (PERFORM/MIDI)
is OFF.
❍Portamento (Controller number 65)
Status 2nd byte 3rd byte
BnH 41H vvH
n = MIDI channel number: 0H - FH (Ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
* In Performance mode the Part Portamento Switch parameter (PERFORM/PART) will
change.
❍Sostenuto (Controller number 66)
Status 2nd byte 3rd byte
BnH 42H vvH
n = MIDI channel number: 0H - FH (Ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
❍Soft (Controller number 67)
Status 2nd byte 3rd byte
BnH 43H vvH
n = MIDI channel number: 0H - FH (Ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
❍Legato Foot Switch (Controller number 68)
Status 2nd byte 3rd byte
BnH 44H vvH
n = MIDI channel number: 0H - FH (Ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
* In Performance mode the Part Legato Switch parameter (PERFORM/PART) will change.
❍Hold-2 (Controller number 69)
Status 2nd byte 3rd byte
BnH 45H vvH
n = MIDI channel number: 0H - FH (Ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
* A hold movement isn't done.
❍Resonance (Controller number 71)
Status 2nd byte 3rd byte
BnH 47H vvH
n = MIDI channel number: 0H - FH (Ch.1 - 16)
vv= Resonance value (relative change): 00H - 7FH (-64 - 0 - +63),
* In Performance mode the Part Resonance Offset parameter (PERFORM/PART) will
change.
❍Release Time (Controller number 72)
Status 2nd byte 3rd byte
BnH 48H vvH
n = MIDI channel number: 0H - FH (Ch.1 - 16)
vv = Release Time value (relative change): 00H - 7FH (-64 - 0 - +63),
* In Performance mode the Part Release Time Offset parameter (PERFORM/PART) will
change.
❍Attack time (Controller number 73)
Status 2nd byte 3rd byte
BnH 49H vvH
n = MIDI channel number: 0H - FH (Ch.1 - 16)
vv = Attack time value (relative change): 00H - 7FH (-64 - 0 - +63),
* In Performance mode the Part Attack Time Offset parameter (PERFORM/PART) will
change.
❍Cutoff (Controller number 74)
Status 2nd byte 3rd byte
BnH 4AH vvH
n = MIDI channel number: 0H - FH (Ch.1 - 16)
vv = Cutoff value (relative change): 00H - 7FH (-64 - 0 - +63)
* In Performance mode the Part Cutoff Offset parameter (PERFORM/PART) will change.
❍Decay Time (Controller number 75)
Status 2nd byte 3rd byte
BnH 4BH vvH
n = MIDI channel number: 0H - FH (Ch.1 - 16)
vv = Decay Time value (relative change): 00H - 7FH (-64 - 0 - +63)
* The decay time will change in GM mode.
❍Vibrato Rate (Controller number 76)
Status 2nd byte 3rd byte
BnH 4CH vvH
n = MIDI channel number: 0H - FH (Ch.1 - 16)
vv = Vibrato Rate value (relative change): 00H - 7FH (-64 - 0 - +63)
* The vibrato rate will change in GM mode.
❍Vibrato Depth (Controller number 77)
Status 2nd byte 3rd byte
BnH 4DH vvH
n = MIDI channel number: 0H - FH (Ch.1 - 16)
vv = Vibrato Depth Value (relative change): 00H - 7FH (-64 - 0 - +63)
* The vibrato depth will change in GM mode.
❍Vibrato Delay (Controller number 78)
Status 2nd byte 3rd byte
BnH 4EH vvH
n = MIDI channel number: 0H - FH (Ch.1 - 16)
vv = Vibrato Delay value (relative change): 00H - 7FH (-64 - 0 - +63)
* The vibrato delay will change in GM mode.
❍General Purpose Controller 5 (Controller number 80)
Status 2nd byte 3rd byte
BnH 50H vvH
n = MIDI channel number: 0H - FH (Ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
* The Tone Level parameter (PATCH/TONE) of Tone 1 will change.
❍General Purpose Controller 6 (Controller number 81)
Status 2nd byte 3rd byte
BnH 51H vvH
n = MIDI channel number: 0H - FH (Ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
