Figure 4-2 YL90T-H functional area distribution interface
The YL90T-H display is equipped with five buttons on the corresponding operating unit: power on/off , plus ,
minus
, light and toggle .
◆
5. Routine operation
5.1
Power on/off
Long press to power on/off the display. When the display is off, it will not use the battery power and the leakagecurrent is less than 1uA.
The display will automatically shut off if it is not used for more than 10 minutes.
5.2
Display interface switching
When the display is powered on, it will show the Current Speed (km/h) and Odometer (km) by default. Short press
to switch between Odometer (km), Trip Odometer(km), Maximum Speed (km/h), and Average Speed (km/h).
