Figure 6-6 Wheel diameter setting interface
6.7 Number of speed sensor magnets setting
07P is the speed sensor magnet number setting. The adjustable speed sensor magnet number range is: 1 ~ 255 pcs..
Press to enter the parameter changing state. Press the
/
to select the parameter and press to save the parameter setting and return to the personalized parameter setting interface.
Figure 6-7 Number of speed sensor magnets setting interface
