Example of air braking system on 2 axles (40 kmh)
Installation of the drive shaft :
PROCEDURE
. All drive shafts must be equipped with safety guards in good
condition.
. Deteriorated guards must be replaced immediately
. Do not forget to install guards and to restrain them with
chains.
. Never operate a PTO without the foreseen guards.
. Wearing loose clothing may be the cause of accidents.
. During the first use, it may be necessary to adjust the length of the drive
shaft. To do this :
Ensure the correct length of the drive shaft tubes.
Tube can be damaged if the turning circle is too severe
Interlock the tubes a minimum of 4500 mm.
On transmissions there are several types of security, safety shear bolt or torque
clutches cams. In case of a shear bolt, it should be replaced by a bolt of the same
type and same quality as the original. Replacement by a stronger bolt will damage
the vehicle.
N.B : for commissioning, operation and maintenance of the transmission
(primary and secondary), refer to the manufacturer's specific instruction
manuals provided with the machine.
