7
4. Den Panoramakopf aufbauen
Montieren Sie den Panoramakopf über das 3/8“ Gewinde an der Basisplatte
Ihres Stativs.
Entfernen Sie nun Knopf „A“ komplett (siehe 1 in Abb. 1) und drehen die
Halterung in die vertikale Position (2). Fixieren Sie die Halterung indem Sie die
Schraube in das dafür vorgesehene Gewinde einschrauben.
A
1
2
3
Abb. 1
